| Ref | Part Number | Description |
|---|
| 1 |
353-426 |
FITTING-90 DEG Price: $29.88 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140839. Price: $149.99 |
| 2 |
237-80 |
O-RING Price: $6.10 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
44-7612 |
BOLT-HWH Price: $24.50 |
| 4 |
353-721 |
PLUG Price: $44.12 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
237-79 |
O-RING Price: $5.46 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
38-5540 |
FITTING-HYD Price: $80.14 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
68-4240 |
BONNET ASSEMBLY Price: $42.76 |
| 10 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 11 |
353-976 |
SCREW Price: $1.49 |
| 12 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
44-7650 |
SPRING Price: $31.84 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
353-959 |
PLATE-RETAINER, SEAL Price: $7.40 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
353-958 |
WASHER Price: $13.57 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
3219-3 |
NUT-HEX Price: $0.34 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
353-799 |
CONVERSION PLUG ASM Price: $87.60 |
| 19 |
237-177 |
O-RING This part replaces 353-800. Price: $2.73 |
| 20 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 21 |
353-798 |
PLATE-COVER, RIGHT Price: $451.34 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
322-13 |
SCREW-HH Price: $2.73 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
353-318 |
WIPER Price: $32.73 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
| 28 |
353-321 |
PIN-COTTER Price: $3.15 |
| 29 |
353-324 |
HANDLE BRACKET Price: $107.74 |
| 30 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 31 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 32 |
52-5900 |
SCREW Price: $26.40 |
| 33 |
52-5670 |
DISCONTINUED X-REF Price: Call Us |
| 34 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 35 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 36 |
353-322 |
PIN-CLEVIS Price: $5.09 |
| 37 |
44-7660 |
DISCONTINUED Price: Call Us |
| 38 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 39 |
353-305 |
O-RING Price: $10.91 |
