| Ref | Part Number | Description |
|---|
| 1 |
21543914 |
KIT, MAIN HOUSING Price: $225.95 |
| 1 |
590518207 |
DEFLECTOR ASSEMBLY RIVETED This part replaces 532444041. Price: $17.99 |
| 1 |
76-5060 |
SCREW-HH Price: $4.84 |
| 2 |
21543983 |
HSG, IZT LOWER Price: $30.60 |
| 2 |
590518207 |
DEFLECTOR ASSEMBLY RIVETED This part replaces 532184113. Price: $17.99 |
| 2 |
76-5010 |
WASHER-SPRING Price: $0.33 |
| 3 |
21543916 |
KIT, C-SECTION Price: $224.45 |
| 3 |
587030801 |
CONTROL.ASM.DEFLEC.BLK.BOWDEN This part replaces 532420673. Price: $54.99 |
| 3 |
94-3260 |
WASHER-FLAT Price: $0.36 |
| 4 |
21543998 |
SEAL, LIP 15X35X7 Price: $4.45 |
| 4 |
532420325 |
SEAL.DEFLECTOR Price: $5.99 |
| 4 |
94-3255 |
SLIDE Price: $15.44 |
| 5 |
21543964 |
WASHER .98X1.37X.04 Price: $1.45 |
| 5 |
532414280 |
KNOB LEVER, BLACK Price: $6.99 |
| 5 |
94-3256 |
BELT Price: $27.50 |
| 6 |
08613300 |
RING, WIRE RETAINING Price: $3.45 |
| 6 |
532128415 |
RIVET BLIND Price: $3.99 |
| 6 |
94-3254 |
SCREW Price: $13.13 |
| 7 |
08608800 |
RING. RETAINING Price: $1.30 |
| 7 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 7 |
94-3253 |
BRACKET-ALTERNATOR Price: $229.65 |
| 8 |
08613200 |
BEARING, SHAFT BALL Price: $15.80 |
| 8 |
532430324 |
SHIELD.SNOW.CHUTE Price: $17.99 |
| 8 |
74-8610 |
PIN-SPRING Price: $2.73 |
| 9 |
532421728 |
STRAP.SHEILD.RETAINER Price: $12.99 |
| 9 |
76-5000 |
BOLT-ADJ. This part replaces 94-3259. Price: $3.06 |
| 10 |
08609000 |
SWASHPLATE. VARIABLE Price: $55.60 |
| 10 |
532179829 |
BOLT, SHOULDER Price: $4.99 |
| 10 |
94-3262 |
NUT-HHF Price: $2.67 |
| 11 |
08609100 |
BEARING. THRUST 30 X 52 X 13 Price: $14.95 |
| 11 |
48-7880 |
NUT-HEX This part replaces 94-3261. Price: $0.25 |
| 11 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 12 |
112-1364 |
ALTERNATOR This part replaces 94-3252. Price: $1,028.33 |
| 12 |
21543719 |
SHAFT, INPUT Price: $71.45 |
| 12 |
596136401 |
Bolts This part replaces 872250505. Price: $2.99 |
| 13 |
21543984 |
COVER, END IZT Price: $23.00 |
| 13 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 13 |
94-3257 |
DISCONTINUED Price: Call Us |
| 14 |
08621500 |
SPRING. BLOCK Price: $1.45 |
| 14 |
532184505 |
SPRING.DEFLECTOR.REM.CHUTE Price: $6.99 |
| 14 |
94-3258 |
CAPSCREW Price: $3.37 |
| 15 |
21543889 |
KIT, 10 CC BLOCK Price: $79.95 |
| 15 |
587030801 |
CONTROL.ASM.DEFLEC.BLK.BOWDEN This part replaces 532420679. Price: $54.99 |
| 19 |
08611200 |
WASHER Price: $3.45 |
| 24 |
08609400 |
WASHER. THRUST .59 X .79 X .04 Price: $1.45 |
| 25 |
21543747 |
BRG, THRUST BALL 42X68X16 Price: $19.15 |
| 26 |
21543738 |
BRG, BALL 17X40X12 Price: $16.45 |
| 27 |
21543960 |
RING, RET WIRE .561 ID Price: $1.45 |
| 30 |
08610700 |
GUIDE. SLOT Price: $3.60 |
| 31 |
08610800 |
ARM. TRUNNION TAPERED SQUARE Price: $45.45 |
| 33 |
21543997 |
SEAL, LIP 12X25X7 Price: $2.25 |
| 38 |
21543918 |
KIT, BYPASS PLATE Price: $6.30 |
| 39 |
08609800 |
ACTUATOR, BYPASS Price: $28.15 |
| 40 |
08613800 |
SEAL, LIP Price: $3.45 |
| 41 |
08611100 |
ARM. BYPASS Price: $12.95 |
| 42 |
08611400 |
RING. RETAINING1 Price: $1.95 |
| 43 |
21543718 |
PIN-HOLLOW .39X.5X1. Price: $3.95 |
| 44 |
21543721 |
HFHCS 3/8-24X2.5 (PATCH) Price: $2.25 |
| 46 |
21543779 |
FILTER Price: $56.45 |
| 50 |
21543759 |
HFHCS 1/4-20X.75 Price: $1.95 |
| 51 |
21543754 |
GEAR, BEVEL 14T Price: $19.05 |
| 52 |
21543755 |
GEAR, BEVEL 19T Price: $25.60 |
| 53 |
21543756 |
GEAR, SPUR 53T Price: $64.50 |
| 54 |
21543761 |
SHAFT, MOTOR Price: $51.95 |
| 55 |
21543827 |
SHAFT, BRAKE Price: $97.40 |
| 56 |
21543757 |
AXLE, 1.0X12.3 Price: $123.95 |
| 58 |
21543816 |
SEAL, LIP 17X40X7 Price: $11.95 |
| 60 |
21543780 |
PLUG, SEAL 1.86 Price: $6.45 |
| 62 |
21543762 |
RING, RET .75 EXT Price: $1.20 |
| 63 |
21543800 |
RING, RET .440 EXT Price: $1.95 |
| 64 |
21543753 |
BRG, BALL 20X47X14 Price: $10.65 |
| 65 |
21543752 |
BRG, BALL 25X47X12 Price: $23.45 |
| 66 |
21543758 |
SEAL, LIP 25X47X7 Price: $5.95 |
| 67 |
21543741 |
RING, RET 1.56 INT Price: $6.45 |
| 68 |
21543763 |
RING, RET 1.87 INT Price: $3.45 |
| 70 |
51514300 |
KIT, LH-BRAKE ARM IZT This part replaces 00372100. Price: $47.45 |
| 73 |
21543760 |
BRAKE, PARK SPLINE Price: $11.45 |
| 81 |
21543864 |
SPACER Price: $4.95 |
| 82 |
21543865 |
SPACER Price: $19.15 |
| 100 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 110 |
07026300 |
FTG-STR .50 O-RING Price: $20.45 |
| 111 |
21543938 |
BREATHER ASSEMBLY Price: $3.95 |
| 126 |
21543828 |
RING, RET 1.43" Price: $1.55 |
| 134 |
21543905 |
KIT, SEAL Price: $49.45 |
| 136 |
02772600 |
FAN-6IN Price: $10.95 |
| 142 |
21543855 |
WASHER, .392 X 1.250 X .0 Price: $2.95 |
| 143 |
21543853 |
CAP, BRAKE Price: $2.15 |
| 207 |
08616400 |
SPACER, TRUNNION Price: $2.45 |
| 208 |
21543832 |
SHCS 5/16-24X.75 Price: $2.95 |
| 209 |
21543876 |
SPRING, EXTENSION Price: $4.45 |
| 210 |
21543833 |
HOSE .5X4 Price: $5.85 |
| 215 |
HG52413 |
Assembly, RTN Price: Call Us |
| 216 |
21543932 |
KIT, CCW RTN SCISSOR Price: $27.90 |
| 217 |
21543941 |
KIT, BREATHER Price: $20.45 |
