| Ref | Part Number | Description |
|---|
| 1 |
112-0378 |
BRACKET-RETAIN, HOOK Price: $6.01 |
| 2 |
112-0370 |
SPINDLE ASM This part replaces 112-6042. Price: $98.48 |
| 3 |
112-0413 |
LH HANGER BRACKET ASM Price: $38.86 |
| 4 |
119-9129 |
DECK ASM Price: $838.89 |
| 5 |
125-0080 |
STOP-DEFLECTOR, CHUTE Price: Call Us |
| 6 |
112-0513 |
SCREW-HH Price: $3.52 |
| 7 |
112-0631 |
SCREW-HH Price: $3.52 |
| 8 |
112-6070 |
SCREW-TAP Price: $3.24 |
| 9 |
112-0373 |
SCREW-HH Price: $3.50 |
| 10 |
112-0524 |
SCREW-HWHTF Price: $3.48 |
| 11 |
119-9111 |
SPRING-TORSION Price: Call Us |
| 12 |
112-0557 |
SCREW-HH Price: $3.52 |
| 13 |
112-0590 |
SCREW-HH Price: $3.52 |
| 14 |
112-0452 |
BOLT-CARR Price: $3.52 |
| 15 |
119-9098 |
PIN-ROLLER Price: $22.32 |
| 16 |
112-0650 |
NUT-LOCK, FLANGE Price: $3.42 |
| 17 |
112-0668 |
NUT-LOCK, FLANGE Price: $3.38 |
| 18 |
112-0330 |
NUT-LOCK, FLANGE Price: $5.46 |
| 19 |
119-8449 |
NUT Price: $4.18 |
| 20 |
112-0351 |
NUT-HEX Price: $4.96 |
| 21 |
112-0437 |
NUT-HEX Price: $3.50 |
| 22 |
112-0568 |
PIN-COTTER Price: $3.63 |
| 23 |
119-8450 |
PIN-LYNCH Price: $9.64 |
| 24 |
112-0574 |
BRACKET-FINGER GUARD Price: $91.16 |
| 25 |
112-0412 |
PIN-COTTER Price: $3.50 |
| 26 |
112-0327 |
GEAR-ADJUSTMENT, DECK Price: $12.35 |
| 27 |
112-0916 |
ADAPTER-NOZZLE, WATER Price: $22.32 |
| 28 |
112-6185 |
DISCONTINUED Price: Call Us |
| 29 |
112-6043 |
SPRING-EXTENSION Price: $15.36 |
| 30 |
119-8451 |
SPRING-CMPRSSN Price: $5.95 |
| 31 |
112-0399 |
SPRING-LIFT, ASSIST Price: $9.37 |
| 32 |
112-0677 |
WHEEL-DECK, FRONT Price: $16.41 |
| 33 |
112-0337 |
WHEEL-DECK, REAR Price: $10.93 |
| 34 |
112-0366 |
DISCONTINUED Price: Call Us |
| 35 |
112-0643 |
WASHER-LOCK Price: $3.52 |
| 36 |
112-0572 |
WASHER-FLAT Price: $3.52 |
| 37 |
119-8455 |
WASHER-BELLVILLE Price: $6.37 |
| 38 |
112-6274 |
NOZZLE-WATER, DECK Price: $23.50 |
| 39 |
112-0334 |
BOLT-SHOULDER Price: $7.65 |
| 40 |
112-0584 |
SPACER-SHOULDER Price: $21.03 |
| 41 |
112-0325 |
BOLT-SHOULDER Price: $8.96 |
| 42 |
112-0316 |
BLADE-17.90 INCH This part replaces 112-6280. Price: $29.54 |
| 43 |
125-0081 |
FRONT DECK LIFT ROD Price: $18.62 |
| 44 |
119-9100 |
PIN-HINGE Price: $12.35 |
| 45 |
119-9130 |
ROD-DECK Price: $26.87 |
| 46 |
112-0436 |
PIN-HANDLE, DECK RELEASE Price: $10.77 |
| 47 |
112-0729 |
BELT-V TYPE Price: $128.25 |
| 48 |
112-0314 |
PULLEY-IDLER Price: $37.20 |
| 49 |
112-5926 |
PULLEY Price: $31.94 |
| 50 |
112-5837 |
SKIRT-CENTER Price: $25.83 |
| 51 |
112-0612 |
SKIRT-RH Price: $22.30 |
| 52 |
112-6041 |
COVER-BELT, LH Price: $69.71 |
| 53 |
112-6040 |
COVER-BELT, RH Price: $69.71 |
| 54 |
112-6057 |
BRACKET-IDLER Price: $47.04 |
| 55 |
119-9102 |
BRACKET-CHUTE Price: $27.03 |
| 56 |
119-9103 |
CHUTE ASM Price: $62.66 |
| 57 |
112-0921 |
WASHER-FLAT Price: $3.52 |
| 58 |
112-0926 |
FITTING-GREASE Price: $3.63 |
| 59 |
112-0884 |
SHAFT-SPINDLE, BLADE (STAR) Price: $27.35 |
| 60 |
112-0377 |
BEARING-BALL Price: $17.50 |
| 61 |
112-6038 |
SPACER Price: $3.65 |
| 62 |
112-0389 |
SPACER Price: $3.52 |
| 63 |
119-9110 |
SPACER Price: $13.22 |
| 64 |
119-8454 |
WASHER-FLAT Price: $4.13 |
| 65 |
119-8474 |
DECAL-DECK WASH SYSTEM Price: $3.59 |
| 66 |
112-6284 |
DECAL-DECK Price: $9.00 |
| 67 |
119-8476 |
DECAL-BELT ROUTING Price: $5.95 |
