| Ref | Part Number | Description |
|---|
| 1 |
3219-3 |
NUT-HEX Price: $0.34 |
| 1 |
487734-18 |
Fitting Orfs to SAE Price: Call Us |
| 2 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 2 |
487735-02 |
Fitting , Reducer-Straight Price: Call Us |
| 3 |
487633 |
Pump, PIM 28cc Price: Call Us |
| 3 |
5-1468-01 |
PNEU. WHEEL HUB This part replaces 5-1468. Price: $101.29 |
| 4 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 4 |
481467-04 |
Connector, O-Ring to Hose Barb Price: Call Us |
| 5 |
487734-24 |
Fitting Orfs to SAE Price: Call Us |
| 5 |
5-1470 |
SCREW-HH Price: $0.61 |
| 6 |
3217-6 |
NUT-HEX Price: $1.19 |
| 6 |
487734-01 |
Fitting Orfs to SAE Price: Call Us |
| 7 |
12-9460 |
DISC HALF Price: $73.84 |
| 7 |
487734-11 |
Fitting Orfs to SAE Price: Call Us |
| 8 |
12-9390 |
TIRE (16X4-12) 4 PLY SEMI-PNEUMATIC Price: $77.30 |
| 8 |
487734-05 |
Fitting Orfs to SAE Price: Call Us |
| 9 |
04001-45 |
Capscrew, Hex Head 3/8-16 x 2.0" Price: Call Us |
| 9 |
322-2 |
SCREW-HH Price: $0.69 |
| 10 |
4200368 |
Bracket, Front Pump Price: Call Us |
| 11 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 12 |
04002-02 |
METRIC HH BOLT 10-1.5 X 30 ZNC Price: Call Us |
| 13 |
487909 |
Isolator, Flange Mount Price: Call Us |
| 14 |
04041-38 |
Flatwasher, 3/8-.406 x 2.25" x .1875 Price: Call Us |
| 15 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 16 |
482266-04 |
Elbow 90 - O-Ring Price: Call Us |
| 17 |
487745 |
Sight Glass, SAE 16 W/Reflector Price: Call Us |
| 18 |
431213-01 |
Boss, Weld SAE ORB Price: Call Us |
| 19 |
487734-23 |
Fitting Orfs to SAE Price: Call Us |
| 20 |
482266-05 |
Elbow, 90 - O-Ring 1 1/16-12 Price: Call Us |
| 21 |
487651 |
Cap Assy, Hydraulic Sealed Price: Call Us |
| 22 |
04010-12 |
Screw, Hex-Slotted Washer Head #10 32 x 3/4" Price: Call Us |
| 23 |
487820 |
Breather, Hydraulic Price: Call Us |
| 24 |
04017-16 |
Capscrew, 5/16-18 x .75 Serrated Flange Hex Head Price: Call Us |
| 25 |
487642 |
Filter, Hydraulic Oil Price: Call Us |
| 26 |
463657 |
Hydraulic Tank Assy (Incl. 16, 17, 19, 20, 21, 22, 23, 24, 25, 27) Price: Call Us |
| 27 |
487858 |
Switch, Oil Temp Price: Call Us |
| 28 |
487744 |
Wheel Motor, RH Price: Call Us |
| 29 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 30 |
487734-13 |
Fitting Orfs to SAE Price: Call Us |
| 31 |
04003-11 |
SHORT SQ. NECK CARRIAGE BOLT, 3/8-16 X 1-1/4" Price: Call Us |
| 32 |
429430 |
Plate, Front Price: Call Us |
| 33 |
423279 |
Plate Weldment, Motor Backing Price: Call Us |
| 34 |
487637 |
Wheel Motor - LH Price: Call Us |
| 35 |
04001-234 |
Capscrew Hex Head 1/2-13 UNC X 1.25 Price: Call Us |
| 36 |
04043-05 |
Flatwasher, 1/2 SAE Hardened Price: Call Us |
| 37 |
487734-10 |
Fitting Orfs to SAE Price: Call Us |
| 38 |
04017-05 |
Bolt, Serrated Flange Hex Head 1/4 x 20 x 3/4" Price: Call Us |
| 40 |
488451 |
Seal Kit, PM10 Price: Call Us |
| 488444 |
Seal |
Kit, PIM 28cc Price: Call Us 488444 |
| 488445 |
Input |
Shaft Seal Price: Call Us 488445 |
