| Ref | Part Number | Description |
|---|
| 1 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 2 |
532123583 |
SQUARE KEY Price: $2.69 |
| 3 |
28-9570-03 |
LEVER-PUMP Price: $264.06 |
| 4 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 5 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 6 |
46-8810 |
STOP-SPRING, LEAF Price: $9.17 |
| 7 |
3219-2 |
NUT-HEX Price: $0.37 |
| 8 |
29-6120-03 |
PUMP PLATE ASM Price: $93.02 |
| 9 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 10 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 11 |
322-17 |
SCREW-HH Price: $2.62 |
| 12 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 13 |
321-6 |
SCREW-HH Price: $0.25 |
| 14 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 15 |
251-259 |
BEARING-BALL Price: $13.67 |
| 15 |
819131316 |
WASHER Price: $2.99 |
| 16 |
3210-7 |
SCREW-HH Price: $0.61 |
| 17 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 17 |
532197297 |
SPRING.BRAKE.PEERLESS.TEX Price: $3.99 |
| 18 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 19 |
51-3150 |
SHIM-ARM, SPRING Price: $5.24 |
| 20 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 21 |
3217-16 |
NUT-HEX Price: $0.25 |
| 22 |
532416614 |
Price: $27.99 |
| 23 |
532121274 |
KNOB.DUCKHEAD.1/2 Price: $5.99 |
| 26 |
532197455 |
SPRING.BRAKE.RTN.GR.DR Price: $2.99 |
| 29 |
532197267 |
ROD.BRAKE.PEERLESS Price: $22.99 |
| 33 |
812000001 |
E-RING LT Price: $2.99 |
| 35 |
532401031 |
ROD, BRAKE, PARK Price: $12.99 |
| 37 |
532121749 |
WASHER Price: $1.99 |
| 42 |
532008883 |
Cover, Pedal This part replaces 532124872. Price: $3.49 |
| 49 |
872110614 |
BOLT Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $9.99 |
| 51 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $9.99 |
| 56 |
532138255 |
BELT, V GROUND DRIVE 95 25 Price: $25.99 |
| 61 |
532165999 |
Price: $38.99 |
| 64 |
532196200 |
SHAFT.ASM.PEDAL.BRAKE. Price: $22.99 |
| 73 |
874490540 |
BOLT Price: $2.99 |
| 116 |
873900500 |
NUT LOCK HEX FLANGE 5/16-18 Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.49 |
| 134 |
532197857 |
ARM SHIFT Price: $2.99 |
| 139 |
871040412 |
Bolt, Shift Plate This part replaces 874550412. Price: $3.99 |
| 140 |
810040400 |
LOCKWASHER Price: $3.99 |
| 141 |
734115201 |
WASHER - M6 This part replaces 819091210. Price: $1.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 155 |
532002267 |
Ring, Retaining This part replaces 812000028. Price: $3.99 |
| 157 |
532105701 |
WASH-SHFT PLT LT Price: $3.99 |
| 158 |
532194352 |
KEEPER.PMS.18/20.D4365 Price: $11.99 |
| 159 |
876020412 |
COTTER PIN Price: $3.99 |
| 160 |
532169484 |
RETAINER CLIP Price: $4.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $7.99 |
| 165 |
532196212 |
BUSHING.SHAFT.BRAKE.HAND Price: $2.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $2.99 |
| 167 |
532405257 |
LATCH.BRAKE.SPRING Price: $2.99 |
| 172 |
532197657 |
STRAP.TRQ.LH.GEAR.DRIV Price: $3.99 |
| 174 |
532197289 |
NUT.PUSH.500.2006 Price: $2.99 |
| 175 |
532197858 |
SHAFT ASM SHIFT Price: $14.99 |
| 176 |
532196214 |
ARM.CLEVIS.ROD.SHIFT Price: $4.99 |
| 178 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $3.99 |
| 184 |
532199996 |
HANDLE.PARKG.BRK.PRED.LT This part replaces 532441407. Price: $7.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $3.99 |
| 187 |
532413524 |
WASHER.13/32 X 1 X 1/2.11GUARD This part replaces 819133210. Price: $2.99 |
| 188 |
532194323 |
LINK.CLUTCH.GROUND.DRIVE Price: $7.99 |
| 189 |
532194317 |
BELLCRANK.GROUND.DRIVE.TEX. Price: $3.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $4.99 |
| 192 |
873610400 |
NUT This part replaces 532150360. Price: $2.99 |
| 193 |
532171877 |
Bolt 5/16-18 unc x 3/4 This part replaces 817060512. Price: $3.99 |
| 195 |
532197332 |
BRKT.ROD.BRAKE.PEERLES Price: $2.99 |
| 202 |
532197859 |
LINK.SHIFT.PMST.18" Price: $25.99 |
| 203 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.02 |
| 205 |
532121748 |
WASHER Price: $1.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $2.99 |
| 232 |
874780716 |
BOLT FIN HEX 7/16-14 X 1 Price: $2.99 |
| 233 |
532405296 |
WASHER SERRATED Price: $3.99 |
| 263 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 268 |
532182402 |
Price: $4.99 |
| 275 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131614. Price: $3.99 |
| 287 |
532421648 |
Price: $3.99 |
| 288 |
532416617 |
Price: $2.99 |
| 289 |
532417520 |
Price: $2.99 |
| 290 |
532420014 |
Price: $14.99 |
