| Ref | Part Number | Description |
|---|
| 2 |
712-0318 |
HEX JAM NUT 5/8-18 Not Available Price: |
| 3 |
736-0317 |
Bell-Wash. .630" I.D. x 1.25" Price: $6.99 |
| 9 |
711-0640 |
Stud 3/8-16 x 2.75" Lg. Price: $7.03 |
| 10 |
912-3008 |
Jam Nut, 3/8-16 This part replaces 712-0342. Price: $4.08 |
| 11 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 12 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 13 |
16706 |
BRACKET-HANGER Not Available Price: |
| 15 |
736-0217 |
L-Wash. 3/8" I.D. Hd. Price: $3.86 |
| 18 |
710-0924 |
Truss Mach. Scr. 1/4-20 x.75" Lg. This part replaces 710-0255. Price: $4.02 |
| 20 |
748-0300 |
Blade Adapter Not Available Price: |
| 22 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 23 |
710-1039 |
Hex Bolt 3/8-24 x 1" Lg. This part replaces 710-0152. Price: $4.02 |
| 24 |
710-0888 |
Hex Bolt 5/16-24 x 1.0" Lg. Price: $3.86 |
| 26 |
912-3057 |
Hex Nut 5/16-24 Thd. This part replaces 712-0123. Price: $5.94 |
| 30 |
910-0289 |
Hex Bolt 1/4-20 x .50" Lg. This part replaces 710-0289. Price: $3.15 |
| 32 |
912-0287 |
HEX NUT 1/4-20 Not Available This part replaces 7120287. Price: |
| 33 |
911-0792 |
Hinge Pin This part replaces 7110792. Price: $4.05 |
| 34 |
631-05229 |
CHUTE ASSEMBLY This part replaces 7311032. Price: $71.37 |
| 41 |
732-0157 |
Extension Spring Price: $13.40 |
| 42 |
726-0201 |
Push Speed Nut Price: $6.01 |
| 45 |
710-0118 |
Hex Bolt 5/16-18 x .75" Price: $3.76 |
| 46 |
16053 |
BRACKET AS Not Available Price: |
| 47 |
748-0234 |
Shoulder Spacer .500" Dia. Price: $3.86 |
| 49 |
954-0264 |
V-Belt 1/2 " x 52" Lg. This part replaces 754-0264. Price: $45.44 |
| 51 |
710-0176 |
Hex Bolt 5/16-18 x 2.75" Price: $3.89 |
| 53 |
15625B |
LOWER OUTSIDE BELT AUARD Not Available Price: |
| 54 |
732-0602A |
Torsion Spring Not Available This part replaces 7320602. Price: |
| 55 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 56 |
714-0104 |
Int. Cot. Pin 5/16" Dia. Price: $3.90 |
| 57 |
727-0296 |
BRAKE CABLE Not Available Price: |
| 58 |
736-0142 |
Fl-Wash. .281" I.D. x .50" Price: $3.95 |
| 59 |
911-0701 |
Clevis Pin 1/4" Dia. x .53" Lg. This part replaces 711-0701. Price: $5.99 |
| 60 |
15626B-0637 |
BELT GUARD-LOWER Not Available This part replaces 15626A. Price: |
| 61 |
726-0106 |
PUSH NUT This part replaces 7260106. Price: $3.37 |
| 63 |
714-0145 |
Int. Cotter Pin 1/2" Dia. Price: $4.42 |
| 64 |
736-0160 |
Fl-Wash. .531" I.D. x .930" Price: $3.90 |
| 65 |
747-0428 |
Deck Link 3.9" Lg. Price: Call Us |
| 67 |
717-0916 |
BLADE SPINDLE ASS'Y. COMP. Not Available Price: |
| 68 |
15621A |
BRACKET-DE Not Available Price: |
| 69 |
703-1693A |
Hinge Mtg. Brkt. This part replaces 7031693. Price: $20.29 |
