| Ref | Part Number | Description |
|---|
| 1 |
144-4153 |
RESERVOIR-HYDRAULIC This part replaces 120-9077. Price: $784.00 |
| 2 |
323-20 |
SCREW-HH Price: $1.28 |
| 2 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $39.99 |
| 3 |
108-1605 |
BUMPER-RECESS Price: $10.02 |
| 4 |
121-1456 |
SPACER-THIN Price: $5.19 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
115-9793 |
BREATHER Price: $53.38 |
| 7 |
136-8531 |
GROMMET This part replaces 104-0790. Price: $3.62 |
| 8 |
114-0002 |
PIPE-STAND Price: $70.85 |
| 9 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 11 |
237-101 |
O-RING Price: $2.80 |
| 12 |
112-6365 |
DIPSTICK Price: $73.81 |
| 12 |
586729001 |
PULLEY.ENGINE This part replaces 532401985. Price: $27.99 |
| 14 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 15 |
322-7 |
SCREW-HH Price: $0.89 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 17 |
121-1533 |
SPACER-THICK Price: $9.82 |
| 18 |
115-7721 |
NUT-CLIP, U Price: $0.81 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 19 |
121-1557-0P |
MOUNT-TANK This part replaces 121-1557-03. Price: $18.23 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
322-13 |
SCREW-HH Price: $2.73 |
| 23 |
353-508 |
PLUG-HH Price: $7.96 |
| 24 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 25 |
120-8810 |
HOSE-STRAINER Price: $38.16 |
| 26 |
2412-36 |
CLAMP-HOSE This part replaces 115-5436. Price: $1.28 |
| 27 |
114-4920 |
HOSE Price: $6.72 |
| 28 |
121-1521 |
HOSE Price: $15.83 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
