| Ref | Part Number | Description |
|---|
| 1 |
159944X428 |
Wheel, Steering Price: Call Us |
| 1 |
98-1471 |
WHEEL-STEERING Price: $145.99 |
| 2 |
137094 |
Axle Asm., Front Price: Call Us |
| 2 |
98-1459 |
DECAL Price: $3.93 |
| 3 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 3 |
6855M |
Fitting, Grease Price: Call Us |
| 4 |
161849 |
Spindle Asm, LH Price: Call Us |
| 4 |
21-9260 |
COVER-DUST Price: $8.19 |
| 5 |
161848 |
Spindle Asm., RH Price: Call Us |
| 5 |
233-17 |
KNOB Price: $10.58 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 6 |
87-6620 |
SCREW Price: $1.29 |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
93-7998-03 |
PLATE-INSTRUMENT Price: $40.21 |
| 9 |
104-2541 |
SWITCH ASM Price: $36.70 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 10 |
74781044 |
Bolt, Fin Hex 5/8-11 x 2-3/4 Price: Call Us |
| 10 |
95-1821 |
SPRING-COMPRESSION This part replaces 95-1821-03. Price: $6.71 |
| 11 |
136518 |
Spacer, Brg. Axle Front Price: Call Us |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 12 |
73901000 |
Nut, Lock Flange 5/8-11 Unc Price: Call Us |
| 13 |
104-1492 |
ROD ASM Price: $65.49 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
98-3912 |
TUBE ASM Price: $113.52 |
| 15 |
7810H |
Nut Lock Center 3/8-24 Unf Price: Call Us |
| 15 |
98-3910 |
TUBE ASM Price: $115.74 |
| 16 |
145103 |
Shaft Asm., Steering Price: Call Us |
| 16 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 17 |
137347 |
Rod Tie Service Price: Call Us |
| 17 |
63-7900-03 |
RACK Price: $144.55 |
| 18 |
137155 |
Draglink, Ball Joint Solid Vgt Price: Call Us |
| 18 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 19 |
156011 |
Support Asm., Steering Vgt Price: Call Us |
| 19 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 20 |
163887X428 |
Boot Steering Stealth Price: Call Us |
| 20 |
98-3908 |
TUBE ASM Price: $92.85 |
| 21 |
159945 |
Adapter, Wheel Steering Price: Call Us |
| 21 |
94-9951 |
COLUMN-STEERING Price: $366.29 |
| 22 |
155105 |
Bushing, Strg. Price: Call Us |
| 22 |
98-3909 |
TUBE ASM Price: $85.32 |
| 23 |
152927 |
Screw Price: Call Us |
| 23 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 24 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 25 |
33103-020 |
SCREW-HHF Price: $2.16 |
| 25 |
74780616 |
Bolt, Fin Hex 3/8-16 x 1 Gr. 5 Price: Call Us |
| 26 |
130-7945 |
VALVE-STEERING CONTROL This part replaces 99-8959. Price: $1,130.87 |
| 26 |
159946X428 |
Insert Cap Strg WH Price: Call Us |
| 27 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 27 |
3366R |
Bearing, Col. Strg. Price: Call Us |
| 28 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
| 28 |
17000612 |
Screw Hexwsh thdr 3/8-16 x 3/4 Price: Call Us |
| 29 |
104239X |
Bearing, Flange Price: Call Us |
| 29 |
75-2810 |
BRACKET-COLUMN, STEERING Price: $11.01 |
| 30 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 31 |
138136 |
Bushing, Nyliner Snap Price: Call Us |
| 31 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 32 |
19111610 |
Washer 11/32 x 1 x 10 Ga. Price: Call Us |
| 32 |
93-1263 |
DECAL-TOWER Price: $46.56 |
| 33 |
10040500 |
Washer, Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 33 |
104-9324 |
SPEEDOMETER Price: $312.55 |
| 34 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 34 |
74780412 |
Bolt, Hex Hd 5/16-18 x 3/4 Price: Call Us |
| 35 |
107-2562 |
NUT-HEX This part replaces 94-9952. Price: $19.95 |
| 35 |
138059 |
Gear, Sector Steering Price: Call Us |
| 36 |
137156 |
Tie Rod Price: Call Us |
| 36 |
98-3911 |
TUBE ASM Price: $108.87 |
| 37 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 37 |
73360600 |
Jam Nut RH Thread Price: Call Us |
| 38 |
109850X |
Joint Asm. Ball RH Thread Price: Call Us |
| 38 |
322-7 |
SCREW-HH Price: $0.89 |
| 39 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 39 |
73700600 |
Nut Hex Jam 3/8-24 Price: Call Us |
| 40 |
109851X |
Joint Asm. Ball LH Thread Price: Call Us |
| 40 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 41 |
155246 |
Bracket Switch Interlock Vgt 97 Price: Call Us |
| 41 |
69-8970 |
SPACER Price: $9.57 |
| 42 |
17490508 |
Screw Thdrol 5/16-18 x 1/2 Tyt Price: Call Us |
| 42 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 43 |
340-70 |
NUT-LOCK Price: $2.10 |
| 44 |
160135X428 |
Extension Steering Price: Call Us |
| 44 |
69-8940 |
WASHER Price: $1.76 |
