| Ref | Part Number | Description |
|---|
| 1 |
144927 |
Battery Price: Call Us |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
74760412 |
Bolt Hex Head 1/4-20 x 3/4 Price: Call Us |
| 3 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 4 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 6 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 7 |
3274-81 |
SCREW-HSH Price: $0.74 |
| 8 |
105-9851 |
ROTATING KIT Price: $1,864.08 |
| 8 |
186491 |
Box Battery Price: Call Us |
| 9 |
105-4572 |
SERVO PISTON ASM Price: $640.29 |
| 10 |
94-3032 |
FOLLOWER-PISTON This part replaces 105-9852. Price: $574.71 |
| 11 |
105-9853 |
PLATE-COVER Price: $142.29 |
| 16 |
176138 |
Switch Interlock Push-In Price: Call Us |
| 17 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 18 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 19 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 20 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 21 |
105-2857 |
VALVE-RELIEF Price: $1,042.90 |
| 21 |
183759 |
Harness Socket Light W/4152J Price: Call Us |
| 22 |
105-2857 |
VALVE-RELIEF Price: $1,042.90 |
| 22 |
4152J |
Bulb Light Price: Call Us |
| 23 |
323-45 |
SCREW-HH Price: $0.68 |
| 24 |
400253 |
Cable Battery Price: Call Us |
| 25 |
401662 |
Cable Starter Price: Call Us |
| 26 |
175158 |
Fuse Price: Call Us |
| 26 |
3274-59 |
SCREW-HSH Price: $1.15 |
| 27 |
105-9854 |
PLATE-VALVE Price: $441.04 |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 28 |
105-9855 |
HOUSING ASM Price: $1,494.14 |
| 28 |
145491 |
Cable, Ground Price: Call Us |
| 29 |
105-9856 |
BACKPLATE ASM Price: $1,111.73 |
| 29 |
401545 |
Switch, Seat Price: Call Us |
| 30 |
193350 |
Switch, Ign Price: Call Us |
| 31 |
105-2861 |
SHAFT-DRIVE Price: $431.22 |
| 33 |
140401 |
Key, Ignition Price: Call Us |
| 34 |
110712X |
Switch Light / Reset Price: Call Us |
| 34 |
3217-5 |
NUT-HEX Price: $0.25 |
| 36 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 40 |
194276 |
Harness Ign. Price: Call Us |
| 41 |
17720408 |
Screw Thd Cut 1/4-20 x 1/2 Price: Call Us |
| 42 |
131563 |
Cover, Terminal Price: Call Us |
| 43 |
105-3331 |
SEAL-SHAFT Price: $35.63 |
| 43 |
192507 |
Solenoid Price: Call Us |
| 46 |
401763 |
Gauge Hourmeter Price: Call Us |
| 47 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 48 |
93-6306 |
CONTROL ASM Price: $1,822.55 |
| 51 |
105-2909 |
ORIFICE-CONTROL, .036 DIA Price: $20.39 |
| 52 |
94-3041 |
ORIFICE-CONTROL (.028 DIA) Price: $26.81 |
| 55 |
17060512 |
Screw Thdrol 5/16-18 x 3/4 TYTT Price: Call Us |
| 57 |
105-2864 |
VALVE-BYPASS Price: $126.09 |
| 60 |
94-3030 |
WASHER Price: $6.24 |
| 61 |
3256-77 |
WASHER-FLAT Price: $1.60 |
| 71 |
401098 |
Harness Ign. Dash Price: Call Us |
| 90 |
180449 |
Cover Terminal Battery Price: Call Us |
| 91 |
190270 |
Strap Battery Mount Front Price: Call Us |
| 99 |
17670412 |
Screw Hexwsh Thdrol 1/4-20 x 3/4 Price: Call Us |
