| Ref | Part Number | Description |
|---|
| 1 |
532176027 |
DECK.SVC.42".BLACK This part replaces 532165892. Price: $329.99 |
| 1 |
85-6540 |
STUD-DRIVE Price: $7.41 |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 2 |
85-8290 |
TIRE-2PLY, KNOBBY Price: $120.96 |
| 3 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 4 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 4 |
532165460 |
BRACKET SWAY BAR 42" DECK Price: $11.99 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 5 |
93-6838-03 |
HUB-WHEEL This part replaces 93-6838. Price: $72.59 |
| 6 |
325-14 |
SCREW-HH Price: $2.64 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 7 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 8 |
3217-9 |
NUT-HH Price: $0.37 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 9 |
10-6850 |
DRUM-BRAKE Price: $54.08 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
70-9870 |
PLATE-BACKING Price: $183.14 |
| 11 |
84-1990 |
ROD-ADJUSTING Price: $17.37 |
| 12 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000. Price: $8.08 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 13 |
92-1715 |
SPACER Price: $7.99 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 14 |
93-6850 |
LEVER-BRAKE Price: $59.75 |
| 15 |
282-2 |
YOKE Price: $30.04 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
321-4 |
SCREW-HH Price: $0.99 |
| 18 |
3220-2 |
NUT-JAM Price: $0.50 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 23 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 23 |
529845901 |
SERVICE KIT BRKT This part replaces 532177563. Price: $4.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
95-0625 |
ROD-TRAVERSE Price: $90.51 |
| 25 |
115-6699 |
BRAKE ROD ASM This part replaces 95-0628. Price: $93.68 |
| 25 |
532123713 |
SPRING TORSION Price: $6.99 |
| 26 |
27-2320 |
BEARING Price: $15.22 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK This part replaces 532171859. Price: $34.99 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga Price: $5.99 |
| 29 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
83-9310 |
RH BRAKE LEVER ASM Price: $67.19 |
| 31 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9850. Price: $42.42 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 32 |
70-9880 |
SPRING-RETURN Price: $11.81 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 33 |
70-9840 |
SHOE-BRAKE Price: $60.36 |
| 34 |
114-4643 |
WHEEL This part replaces 94-6116. Price: $149.61 |
| 34 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 35 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 36 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9860. Price: $42.42 |
| 36 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 44 |
532140088 |
GUARD MANDREL LH BLACK Price: $29.99 |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 48 |
532133944 |
WASHER Price: $3.99 |
| 52 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 53 |
531168401 |
SERVICE KIT ARM BRAKE ASSY This part replaces 532184907. Price: $19.99 |
| 54 |
532178515 |
WASHER Price: $5.99 |
| 55 |
531166601 |
SERVICE KIT ARM ARM IDLER 42" This part replaces 532155046. Price: $14.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 129 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 130 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 131 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 142 |
529845801 |
SERVICE KIT ARM SPRING BRAKE M This part replaces 532165890. Price: $5.99 |
| 143 |
529844301 |
SERVICE KIT BRACKET This part replaces 532157109. Price: $7.99 |
| 144 |
532173441 |
KEEPER BELT 42" CLUTCH This part replaces 532158634. Price: $6.99 |
| 145 |
532173437 |
PULLEY.IDLER.FLAT.PLATED This part replaces 532165888. Price: $24.99 |
| 146 |
532173443 |
BOLT CARRIAGE IDLER This part replaces 532171977. Price: $4.99 |
| 147 |
532179748 |
SPRING This part replaces 532131335. Price: $4.99 |
| 148 |
532169022 |
IDLER RETURN SPRING Price: $4.99 |
| 149 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 150 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 151 |
532169670 |
BRACKET.CLUTCH.CABLE Price: $17.99 |
| 152 |
532175067 |
KIT.CLUTCH.CABLE This part replaces 532169676. Price: $39.99 |
| 153 |
596140201 |
Washers This part replaces 532169674. Price: $2.99 |
| 154 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 155 |
532169671 |
SPRING RETENTION LEVER Price: $4.99 |
| 156 |
532169672 |
SPACER.CLUTCH.CABLE Price: $4.99 |
| 157 |
532169669 |
ROD CLUTCH CABLE 3/8" Price: $27.99 |
| 158 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 159 |
596987501 |
Bolts This part replaces 872140614. Price: $3.99 |
| 184 |
596134901 |
GSPH This part replaces 819131410. Price: $2.99 |
