| Ref | Part Number | Description |
|---|
| 1 |
76-6010 |
SPACER Price: $18.94 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 2 |
76-4240 |
DISCONTINUED Price: Call Us |
| 3 |
3274-87 |
SCREW-HSFH Price: $1.09 |
| 4 |
74-3640 |
DISC-MIDDLE Price: $195.30 |
| 5 |
106-1021 |
DISC-ACTUATING This part replaces 74-3630. Price: $320.62 |
| 6 |
322-1 |
SCREW-HH Price: $0.22 |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 8 |
76-8300-03 |
COVER-HOUSING, AXLE This part replaces 76-8300. Price: $14.53 |
| 9 |
32128-50 |
NUT-FLANGE Price: $1.78 |
| 10 |
84-1620-03 |
PLATE-SUPPORT, AXLE This part replaces 84-1620. Price: $19.85 |
| 11 |
88-1560 |
AXLE HSG *B Price: $1,118.53 |
| 12 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 13 |
74-5440-03 |
DISCONTINUED This part replaces 74-5440. Price: Call Us |
| 14 |
86-5900 |
TIRE (26X12-12) 8-PLY Price: $229.98 |
| 15 |
104-0161 |
RIM This part replaces 217-124. Price: $404.23 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 17 |
23-7270 |
NUT-LUG Price: $10.37 |
| 17 |
532401072 |
SPRING.BRAKE.K46 Price: $6.99 |
| 19 |
3296-67 |
NUT-LOCK, NI Price: $5.05 |
| 20 |
88-1580 |
SEAL Price: $103.21 |
| 21 |
32151-88 |
RING-RETAINING Price: $3.73 |
| 22 |
88-1590 |
BEARING-BALL Price: $61.63 |
| 23 |
84-1590 |
U-BOLT, FRONT AXLE Price: $23.41 |
| 24 |
325-15 |
SCREW-HH Price: $3.19 |
| 25 |
86-5430 |
DISCONTINUED Price: Call Us |
| 26 |
325-4 |
SCREW-HH Price: $0.95 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
88-1570 |
DISCONTINUED Price: Call Us |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 35 |
583864502 |
Rods This part replaces 532199591. Price: $6.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 80 |
531064101 |
SERVICE KIT TORQUE STRAP BLACK This part replaces 532410024. Price: $19.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT This part replaces 532195403. Price: $9.99 |
| 162 |
580457401 |
SPACER.TRANSAXLE.1" This part replaces 532195785. Price: $12.99 |
| 163 |
593861001 |
Rods This part replaces 532401034. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 This part replaces 532197290. Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 169 |
583613301 |
BOLT.HEX.FLNG.5/16-18X3.75 This part replaces 874490560. Price: $4.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196334 |
ARM.TRACTION.ROD.YZ. This part replaces 532199575. Price: $3.99 |
| 185 |
596435101 |
Bolts This part replaces 872110620. Price: $2.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX This part replaces 532401722. Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 226 |
531170501 |
SERVICE KIT BRACKET This part replaces 532401564. Price: $4.99 |
