| Ref | Part Number | Description |
|---|
| 1 |
85109 |
V-Twin 16HP Engine Price: Call Us |
| 2 |
98216 |
Heat Shield Price: Call Us |
| 3 |
77304 |
Engine Support Price: Call Us |
| 4 |
78512GS |
SPPRT, ALT This part replaces 78512. Price: Call Us |
| 5 |
192980GS |
Kit, Valve This part replaces 80270. Price: $16.43 |
| 6 |
192980GS |
Kit, Valve This part replaces 78299. Price: $16.43 |
| 7 |
84582 |
Fuel Tank Cap Price: Call Us |
| 8 |
35097GS |
MNT, VBRTN, 30 DURO This part replaces 35097. Price: $15.30 |
| 9 |
78831BGS |
HHMS, M6-1.0 x 60 (BLACK) This part replaces 78831B. Price: $1.60 |
| 10 |
93615GS |
ASSY, TANK, FUEL, TEST, 5 GAL This part replaces 93615. Price: $155.05 |
| 11 |
92558GS |
CRDL, VTWIN This part replaces 92558. Price: $644.00 |
| 12 |
83465GS |
GROMMET, TANK This part replaces 83465. Price: $3.39 |
| 14 |
84010756 |
WHEEL ASSEMBLY This part replaces 23152. Price: $405.07 |
| 15 |
703454 |
LOCKWASHER, SPLIT 3/8 This part replaces 22237. Price: $2.95 |
| 16 |
5022241 |
DECAL, ProCut Z Text This part replaces 22241. Price: Call Us |
| 17 |
2828635SM |
SCREW-HEX WSHR HD TAP This part replaces 75246. Price: $4.26 |
| 18 |
703988 |
CAPSCREW M8-1.25X16 This part replaces 39253. Price: $2.86 |
| 19 |
22129GS |
WASHER, Lock This part replaces 22129. Price: $2.61 |
| 20 |
92555 |
Control Panel Assembly Price: Call Us |
| 21 |
86494GS |
SCREW, M6-1.0 x 16 LG. WING This part replaces 86494. Price: $2.51 |
| 23 |
195373GS |
WIRE, Ground This part replaces 143-53621. Price: $1.85 |
| 24 |
313085GS |
SCREW This part replaces 86292. Price: $3.35 |
| 25 |
23762GS |
WASHER, #10 Ext. Shakeproof This part replaces 23762. Price: $2.64 |
| 26 |
79661G |
Engine Decal Price: Call Us |
| 27 |
77581GS |
DECAL, AIR BOX, 16H VTW This part replaces 77581. Price: $16.05 |
| 28 |
194799GS |
DECAL, Danger This part replaces 92982. Price: $10.48 |
| 29 |
92512GS |
DECAL, PNL, CNTRL This part replaces 92512. Price: $14.10 |
| 30 |
92613 |
Unit Decal Price: Call Us |
| 31 |
78837 |
Data Plate Decal Price: Call Us |
| 32 |
77816GS |
DECAL, Hot Muffler This part replaces 77816. Price: $3.95 |
| 35 |
62265GS |
GROMMET, Rubber This part replaces 62265. Price: $6.69 |
| 36 |
84132GS |
ASSEMBLY, POWER REGULATOR This part replaces 84132. Price: $31.80 |
| 37 |
93826GS |
DECAL, START INSTRUCTIONS This part replaces 93826. Price: $1.85 |
| 39 |
73054 |
Fuel Shut-Off Decal Price: $14.30 |
| 40 |
93074 |
Heat Shield Price: Call Us |
| 41 |
98214GS |
BRCKT, HTSHLD This part replaces 98214. Price: $16.99 |
| 42 |
56892GS |
CRIMPTITE, 10-24 X 3/8 This part replaces 56892. Price: $2.79 |
| 44 |
5022250SM |
BUSHING, FLANGE, 7/8" This part replaces 22250. Price: $8.42 |
