| Ref | Part Number | Description |
|---|
| 1 |
117-8320 |
SADDLE ASM Price: $3,431.83 |
| 1 |
532170771 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
108-0657 |
PIN-FLAG Price: $39.42 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 6 |
3233-32 |
BOLT-CARRIAGE Price: $8.48 |
| 7 |
117-8305-03 |
SADDLE-PIVOT Price: $20.05 |
| 8 |
325-7 |
SCREW-HH Price: $1.53 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 10 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 112 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
