| Ref | Part Number | Description |
|---|
| 1 |
137-6105 |
SHORT REAR ROLLER ASM (2.5IN DIA)(22IN) This part replaces 114-5406. Price: $478.13 |
| 1 |
532123650 |
Stud 1/4 Turn Price: $3.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
819132012 |
Washer 13/32 x 1-1/4 x 12 Ga. (AYP part number) Price: $2.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 4 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532124852 |
Door, Fender (AYP part number) Price: $3.33 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
817490508 |
Screw, Hex Wsh. Thrdrol. 5/16-18 x 1/2 (AYP part number) Price: $3.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 7 |
532124144 |
Pad, Footrest (AYP part number) Price: $2.96 |
| 8 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
532126995 |
Console, Shift Control (AYP part number) Price: $14.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
532124307 |
Bar, Shift Lock (AYP part number) Price: $2.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532124346 |
Nut, Self-Thd Wsh-Hd 3/16 (AYP part number) Price: $3.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
532123645 |
Assembly, Frame (AYP part number) Price: $41.33 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
532123379 |
Brace, Drawbar (AYP part number) Price: $8.48 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 16 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
532127880 |
Drawbar (AYP part number) This part replaces 532121904. Price: $25.05 |
| 18 |
532126470 |
Clip, Insulated (AYP part number) Price: $3.99 |
| 19 |
532105839 |
Receptacle, 1/4 Turn (AYP part number) Price: $3.99 |
| 20 |
532124881 |
Fender/Footrest (AYP part number) Price: $3.33 |
| 21 |
532105838 |
Retainer, 1/4 Turn (AYP part number) Price: $3.99 |
