| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER Price: $188.53 |
| 1 |
601400073 |
SCREW .25-20X0.62 HHC Price: $5.99 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
601400080 |
WASHER, FLAT .281X.63 Price: $4.99 |
| 3 |
282-4 |
SHACKLE Price: $32.98 |
| 3 |
601400068 |
PLATE, BEARING RETAIN Price: $49.99 |
| 4 |
32151-48 |
E-RING Price: $1.41 |
| 4 |
601400074 |
PLATE & BEARING ASY Price: $29.99 |
| 5 |
601400086 |
NUT .25-20 HEX CTRLOCK Price: $6.99 |
| 5 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 6 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
601400058 |
AUGER HOUSING,21 Price: $329.99 |
| 7 |
601002087 |
SPACER, SLEEVE Price: $4.99 |
| 7 |
98-4548-03 |
BRACKET-SPRING, RH Price: $42.16 |
| 8 |
601400064 |
WASHER .640-1.25-.06 F Price: $5.99 |
| 8 |
98-4536-03 |
BRACKET-SPRING, LH Price: $42.16 |
| 9 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 9 |
601002095 |
PULLEY, RIBBED 6" OD Price: $54.99 |
| 10 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
601001796 |
BLADE, SCRAPER 20.88 P Price: $32.99 |
| 11 |
100-3831-01 |
BRACKET-ROLLER, LH Price: $69.47 |
| 11 |
601400026 |
NUT .25-20 HEX FLG CTR Price: $7.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
601001798 |
AUGER ASSY COMP 21" This part replaces 601400053. Price: $220.99 |
| 13 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 14 |
75-5400 |
PIN-ROLLER Price: $26.06 |
| 15 |
75-5390 |
ROLLER Price: $56.69 |
| 16 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 17 |
75-5360 |
PIN-CYLINDER Price: $72.33 |
| 18 |
108-4432 |
CYLINDER-HYD, LIFT This part replaces 93-9311. Price: $730.09 |
| 19 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 20 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 21 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 22 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 23 |
93-0069-03 |
PIN-REAR Price: $424.34 |
| 25 |
322-6 |
SCREW-HH Price: $0.45 |
| 26 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
