| Ref | Part Number | Description |
|---|
| 1 |
322-3 |
SCREW-HH Price: $0.79 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX Price: $119.99 |
| 3 |
75-2810 |
BRACKET-COLUMN, STEERING Price: $11.01 |
| 4 |
538691101 |
SPINDLE.WLDMT.LH.16IN.TEX.X431 This part replaces 532403089. Price: $19.99 |
| 4 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 5 |
538691001 |
SPINDLE.WLDMT.RH.16IN.TEX.X431 This part replaces 532403090. Price: $19.99 |
| 5 |
68-5370 |
DECAL Price: $6.21 |
| 6 |
32144-21 |
SCREW Price: $0.20 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 8 |
3220-6 |
NUT-JAM Price: $1.25 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
233-17 |
KNOB Price: $10.58 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
75-0580 |
DISCONTINUE Price: Call Us |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
75-1490 |
ROD-BRAKE, PARKING Price: $50.23 |
| 14 |
237-22 |
O-RING Price: $2.43 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532194746. Price: $34.99 |
| 17 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 18 |
75-6230 |
HOSE Price: $133.10 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
75-6240 |
HOSE Price: $137.49 |
| 20 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 21 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
75-5940 |
HOSE Price: $94.45 |
| 24 |
75-6230 |
HOSE This part replaces 75-6220. Price: $133.10 |
| 25 |
75-6250 |
HOSE Price: $175.77 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
75-0600 |
UNIT-STEERING, POWER Price: $1,809.64 |
| 27 |
21-9260 |
COVER-DUST Price: $8.19 |
| 28 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
