| Ref | Part Number | Description |
|---|
| 1 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 1 |
532424551 |
WHEEL.STEERING.MLT.BR.YEL/OVRM Price: $64.99 |
| 2 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 3 |
140-6221 |
LINK AND BUSHING ASSEMBLY This part replaces 16-9759. Price: $70.43 |
| 4 |
93-6981 |
SPACER Price: $4.69 |
| 5 |
3231-40 |
BOLT-CARR, SHORT NECK Price: $1.27 |
| 6 |
115-4263 |
PLATE-SIDE, RH Price: $329.24 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 7 |
115-4260 |
PLATE-SIDE, LH Price: $329.24 |
| 7 |
532121748 |
WASHER Price: $1.99 |
| 8 |
112-8936 |
TUBE-SUPPORT Price: $46.12 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 9 |
112-8935 |
FRAME-CENTER Price: $455.11 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 12 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 13 |
532121749 |
WASHER Price: $1.99 |
| 14 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 16 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 16 |
532194746 |
SHAFT.STEER.STEALTH.DD This part replaces 532408219. Price: $59.99 |
| 17 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 18 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 19 |
532194729 |
PLATE.STEER.DDL.NLT/NG Price: $12.99 |
| 20 |
532432784 |
BOOT, STEERING Price: $4.99 |
| 21 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532186737. Price: $19.99 |
| 22 |
532420537 |
STEERING.SUPT.LOWER. Price: $4.99 |
| 26 |
532424553 |
CAP.WHL.STRNG.MULTI.BRND.YEL Price: $5.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $19.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8""OD Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $2.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $8.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $4.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $3.99 |
| 61 |
532194740 |
DRAGLINK.LH.BALLSTUD.D Price: $44.99 |
| 62 |
532194741 |
DRAGLINK.RH.BALLSTUD.D Price: $44.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $2.99 |
| 67 |
532194737 |
BUSHING.PM.FRONT AXLE Price: $3.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $2.99 |
| 70 |
585338801 |
BRACKET.FRT.DECK.SUSP.RR.MT431 This part replaces 532196197. Price: $5.99 |
