| Ref | Part Number | Description |
|---|
| 1 |
32120-8 |
RING-SNAP Price: $1.76 |
| 1 |
603003107 |
PISTON, ENGINE STD OHV Price: $64.99 |
| 2 |
603003108 |
PISTON, ENGINE .25MM OVER Price: $89.99 |
| 2 |
72-3750 |
BEARING-ROLLER Price: $180.02 |
| 3 |
323-56 |
SCREW-HH Price: $2.18 |
| 3 |
603003109 |
PISTON, ENGINE .50MM OVER Price: $84.99 |
| 4 |
603003110 |
PIN - PISTON Price: $12.99 |
| 4 |
67-9080 |
HOUSING-MOTOR Price: $1,756.34 |
| 5 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 5 |
603003111 |
RING-SET-PISTON STD Price: $49.99 |
| 6 |
25-2650 |
PLUG-VALVE, CHECK Price: $89.01 |
| 6 |
603003112 |
RING-SET-PISTON .25MM OVER Price: $119.99 |
| 7 |
237-86 |
O-RING Price: $5.47 |
| 7 |
603003113 |
RING-SET-PISTON .50MM OVER Price: $119.99 |
| 8 |
25-2640 |
SPRING-VALVE Price: $4.22 |
| 8 |
603003114 |
WEIGHT, COUNTER - BALANCE Price: $159.99 |
| 9 |
25-2490 |
BALL Price: $14.47 |
| 9 |
603000312 |
SHAFT, GUIDE, COUNTER-BALANCE Price: $27.99 |
| 10 |
67-9100 |
GASKET Price: $15.83 |
| 11 |
603003121 |
BOLT Price: $8.99 |
| 12 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 13 |
237-22 |
O-RING Price: $2.43 |
| 13 |
603003121 |
BOLT Price: $8.99 |
| 14 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 14 |
603000338 |
STUD, 6X14 Price: $2.99 |
| 15 |
603000341 |
NUT Price: $9.99 |
| 15 |
88-8220 |
VALVE-BY PASS Price: $189.03 |
| 16 |
25-2610 |
SPRING-VALVE Price: $29.42 |
| 16 |
603003136 |
SHIM, CRANKSHAFT T=1.13 Price: $5.99 |
| 17 |
25-2410 |
VALVE ASM Price: $514.54 |
| 17 |
603003137 |
SHIM, CRANKSHAFT T=1.18 Price: $5.99 |
| 18 |
603003138 |
SHIM, CRANKSHAFT T=1.23 Price: $5.99 |
| 18 |
76-1900 |
O-RING Price: $3.64 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 19 |
603003139 |
SHIM, CRANKSHAFT T=1.28 Price: $5.99 |
| 20 |
119-2895 |
SPLINED SHAFT KIT This part replaces 67-8020. Price: $1,116.09 |
| 20 |
603003140 |
SHIM, CRANKSHAFT T=1.33 Price: $5.99 |
| 21 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 21 |
603003141 |
SHIM, CRANKSHAFT T=1.38 Price: $5.99 |
| 22 |
117-2700 |
HOUSING KIT This part replaces 54-7890. Price: $2,321.28 |
| 22 |
603003142 |
SHIM, CRANKSHAFT T=1.43 Price: $5.99 |
| 23 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 23 |
603003143 |
SHIM, CRANKSHAFT T=1.48 Price: $5.99 |
| 24 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 24 |
603003144 |
SHIM, CRANKSHAFT T=1.53 OHV Price: $5.99 |
| 25 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 25 |
603003145 |
RING, SNAP Price: $1.99 |
| 26 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 26 |
603003146 |
SPACER Price: $19.99 |
| 27 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 27 |
603000345 |
KEY Price: $2.99 |
| 28 |
25-2460 |
PLUG-HH Price: $37.38 |
| 28 |
603003149 |
SEAL, OIL Price: $12.99 |
| 29 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 29 |
603000351 |
O-RING Price: $2.99 |
| 30 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 31 |
83-7260 |
CONE-RELIEF, CHARGE Price: $50.57 |
| 32 |
353-551 |
PLUG-HH Price: $18.48 |
| 33 |
237-80 |
O-RING Price: $6.10 |
| 33 |
603003150 |
BEARING , PLANE OHV Price: $8.99 |
| 34 |
25-2550 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 34 |
603003130 |
GEAR, SPUR Price: $37.99 |
| 35 |
67-8050 |
BEARING-NEEDLE Price: $54.10 |
| 36 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 37 |
322-4 |
SCREW-HH Price: $0.35 |
| 38 |
25-2680 |
GEROTOR ASM Price: $651.02 |
| 39 |
25-2530 |
PIN-STRAIGHT, HEADLESS Price: $21.24 |
| 40 |
25-3190 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 41 |
237-95 |
O-RING Price: $11.97 |
| 42 |
67-9090 |
PLUG Price: $41.68 |
| 43 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 46 |
251-8 |
BEARING-BALL Price: $30.06 |
| 47 |
32151-75 |
RING-RETAINING This part replaces 32120-11. Price: $2.51 |
| 48 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 49 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 50 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 51 |
25-2440 |
PLATE-VALVE, PUMP Price: $491.90 |
| 52 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 53 |
110-6341 |
BEARING-ROLLER This part replaces 46-8400. Price: $41.33 |
| 54 |
93-4132 |
O-RING Price: $6.84 |
| 55 |
92-8918 |
SECTION-CENTER Price: $1,338.76 |
| 57 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 58 |
46-8410 |
SHAFT-MOTOR Price: $968.23 |
| 59 |
25-2400 |
GASKET Price: $19.26 |
| 60 |
93-0312 |
WASHER-HARDENED Price: $0.78 |
| 61 |
75-0170 |
PLUG-THREAD, STRAIGHT This part replaces 92-8776. Price: $18.20 |
| 62 |
92-8777 |
O-RING Price: $3.02 |
