| Ref | Part Number | Description |
|---|
| 1 |
106-1094 |
KIT - RING & PINION This part replaces 100-2555. Price: $1,064.67 |
| 2 |
99-7570 |
BEARING-ROLLER, TAPER Price: $61.91 |
| 3 |
583343001 |
NUT.PUSH.156 This part replaces 532413808. Price: $2.99 |
| 3 |
95-7534 |
CASE-BEARING Price: $176.21 |
| 4 |
106-1065 |
O-RING This part replaces 99-7571. Price: $9.02 |
| 4 |
579785402 |
BAGGER SWAGE TUBE HANDLE ASSY This part replaces 532439612. Price: $44.99 |
| 5 |
583365901 |
FRAME.ASM.TOP.BAGGER.SRD This part replaces 532417632. Price: $89.99 |
| 5 |
99-7572 |
COLLAR-SEAL, OIL Price: $21.01 |
| 6 |
106-1066 |
O-RING This part replaces 99-7573. Price: $5.71 |
| 6 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 7 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 7 |
99-7574 |
SEAL-OIL Price: $4.42 |
| 8 |
583503801 |
SRD.BAGGER.TOP.SUB.ASM This part replaces 532441261. Price: $119.99 |
| 8 |
99-7559 |
WASHER-LOCK Price: $9.82 |
| 9 |
583365801 |
INSERT.HANDLE.BAGGER.SRD This part replaces 532417629. Price: $22.99 |
| 9 |
99-7560 |
NUT-LOCK Price: $27.76 |
| 10 |
532417190 |
FRAME.FRONT.SRD.BAGGER Price: $54.99 |
| 10 |
99-7550 |
SHIM 0.1 Price: $4.34 |
| 10 |
99-7551 |
SHIM 0.2 Price: $4.55 |
| 11 |
532417188 |
TUBING.BRACE.BAGGER.SRD.BLACK Price: $19.99 |
| 11 |
95-7533 |
CASE-GEAR Price: $289.33 |
| 12 |
583391701 |
NUT.SQUARE.1/4 This part replaces 532421793. Price: $3.99 |
| 12 |
99-7575 |
BOLT Price: $4.00 |
| 13 |
583391201 |
SCREW.1/4X1.150.HXWSH This part replaces 532421780. Price: $2.99 |
| 13 |
98-7735 |
STUD This part replaces 100-2556. Price: $1.36 |
| 14 |
583392001 |
BOLT.SHOULDER.HX.WSH.1/4X1.150 This part replaces 532421800. Price: $6.99 |
| 14 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 15 |
583392101 |
SCREW,#8.FLAT.HEAD.DRILL.TIP This part replaces 532421801. Price: $3.99 |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
532421566 |
DEFLECTOR.BAGGER.SRD Price: $12.99 |
| 16 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 17 |
532421749 |
LEVER.BAGGER.FULL.SRD.BLACK Price: $9.99 |
| 18 |
583391001 |
PADDLE.BAGGER.FULL.SRD.BLACK This part replaces 532421750. Price: $9.99 |
| 21 |
583825601 |
BAG.ASM.BAGGER.SRD.HUSQVA.GREY This part replaces 532429981. Price: $129.99 |
| 22 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 23 |
872040410 |
BOLT Price: $3.99 |
| 25 |
583389801 |
SPRING.LATCH.BAGGER.SRD (3 2) This part replaces 532421614. Price: $3.99 |
| 26 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 27 |
583387201 |
GROMMET.RUBBER.SRD This part replaces 532421262. Price: $3.99 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 29 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
