| Ref | Part Number | Description |
|---|
| 1 |
3219-2 |
NUT-HEX Price: $0.37 |
| 1 |
539108474 |
MOUNTING BRACKET Price: $29.99 |
| 2 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 2 |
515989601 |
PULLEY, CRANK Price: $64.99 |
| 3 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 3 |
574890701 |
SHAFT, PILOT Price: $179.99 |
| 4 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 4 |
575509401 |
GEAR BOX, 90 DEGREE Price: $699.99 |
| 5 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 5 |
515990102 |
ISOLATOR, ENGINE Price: $49.99 |
| 6 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 6 |
515989002 |
MOUNT, MOTOR, LT - BLK Price: $102.99 |
| 7 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 7 |
515988802 |
MOUNT, MOTOR, RT - BLK Price: $102.99 |
| 8 |
539103684 |
GROMMET Price: $3.99 |
| 9 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 9 |
515997601 |
PULLEY, DRIVE, DECK Price: $64.99 |
| 10 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 10 |
539106376 |
AIR FILTER ASSY - NON-TURBO Price: $299.99 |
| 11 |
515990401 |
HOSE, AIR INTAKE Price: $22.99 |
| 11 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 12 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 12 |
522453101 |
HCS M10-1.25 X 20 GR 8.8 ZD Price: $4.99 |
| 13 |
12-5450 |
SCREW Price: $7.99 |
| 13 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 14 |
539977692 |
HTB M8-1.125 X 25MM Price: $0.66 |
| 14 |
86-7230 |
GEAR-INPUT, TRANSMISSION This part replaces 21-8150. Price: $610.12 |
| 15 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 15 |
539115578 |
M8X1.25X25 HHB GR8.8 Price: $2.99 |
| 16 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 16 |
593337201 |
SCREW HEXAGON HEAD WITH COLLAR This part replaces 539115648. Price: $2.99 |
| 17 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 17 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 18 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 18 |
539111990 |
HCS 7/16-20 X 2 G8 ZN Price: $2.99 |
| 19 |
3210-7 |
SCREW-HH Price: $0.61 |
| 19 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 20 |
21-7850 |
PLUG-CUP Price: $23.35 |
| 20 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539990206. Price: $3.99 |
| 21 |
43-6550 |
RING-SNAP Price: $0.94 |
| 21 |
521998801 |
HCS MB 1.25 X 35 GR 8.8 ZD Price: $1.99 |
| 22 |
46-2210 |
SHIM-BEARING, FRONT Price: $6.91 |
| 22 |
46-2216 |
SHIM-FRONT BEARING, .043 Price: $6.69 |
| 22 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 23 |
254-91 |
CONE-BEARING Price: $18.65 |
| 23 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 24 |
254-90 |
BEARING-CUP Price: $11.29 |
| 24 |
525834202 |
Screws This part replaces 525834201. Price: $3.99 |
| 25 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 25 |
539107475 |
BOLT 5/16-18 X 3/4 Price: $4.99 |
| 26 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 26 |
86-9580 |
UPPER HOUSING SUB ASM This part replaces 68-9770. Price: $961.30 |
| 27 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 27 |
539111844 |
WASHER, HEAVY Price: $3.99 |
| 28 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 28 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 29 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 30 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 30 |
539122388 |
SCREW M8X1.25X16 HHB GR 8.8 Price: $2.99 |
| 31 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 31 |
539102067 |
KEY 1/4 SQ X 3/4 Price: $2.99 |
| 32 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 32 |
539124775 |
SCREW 7/16-20 X 1 HHB GR5 Price: $6.99 |
| 33 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 33 |
539117980 |
NUT M6 X 1.0 HEX Price: $2.99 |
| 34 |
43-6840 |
HOUSING-LOWER Price: $1,467.48 |
| 34 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 35 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 35 |
539106384 |
CLAMP Price: $3.99 |
| 36 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 36 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 37 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 37 |
522545201 |
BRACKET, THROTTLE Price: $13.99 |
| 38 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 38 |
522545301 |
SWIVEL, THROTTLE Price: $10.99 |
| 39 |
522752701 |
CLAMP, CABLE Price: $9.99 |
| 39 |
72-9420 |
VENT Price: $6.85 |
| 40 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 41 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 42 |
539990555 |
COTTER PIN 3/32 X 1/2 Price: $1.99 |
| 43 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 44 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 45 |
575244505 |
KIT.SPARK.ARRESTER Price: $49.99 |
| 46 |
539109556 |
WASHER 5/16 EXT STAR Price: $2.99 |
| 47 |
575420403 |
SHIELD, HEAT Price: $80.99 |
| 48 |
539108473 |
PRECLEANER ASM Price: $150.99 |
| 49 |
539115610 |
WASHER .515 X .874 X .031 Price: $2.99 |
| 50 |
574804001 |
CLUTCH, OGURA, DIESEL Price: $599.99 |
| 51 |
574803901 |
YOKE, CLEVIS Price: $12.99 |
| 52 |
574804501 |
PIN, PIVOT Price: $24.99 |
| 53 |
574803801 |
LINKAGE, ANTI-ROTATION Price: $64.99 |
| 54 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 55 |
574751402 |
MOUNT, GEAR BOX, BLK Price: $279.99 |
| 56 |
574804301 |
TENSIONER, LOVEJOY, SE27 Price: $109.99 |
| 57 |
574753301 |
PULLEY, GEAR BOX Price: $282.99 |
| 58 |
574394201 |
MOUNT, IDLER Price: $17.99 |
| 59 |
574890401 |
PLATE, PULLEY Price: $11.99 |
| 60 |
539125626 |
BLADE WASHER Price: $6.99 |
| 61 |
574888203 |
MOUNT, GEAR BOX, BLK Price: $129.99 |
| 62 |
574890601 |
PIN, DETENT Price: $31.99 |
| 63 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 64 |
574890501 |
SPRING, COMPRESSION Price: $9.99 |
| 65 |
574804101 |
BELT, CLUTCH Price: $99.99 |
| 66 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 67 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 68 |
573975201 |
NUT, 7/16-20 HEX NYLOC ZC Price: $2.99 |
| 69 |
539991120 |
BOLT 7/16F X 2 1/2 Price: $5.99 |
| 70 |
539990870 |
E RING 3/8" Price: $2.99 |
| 71 |
539108470 |
BODY - 90 DEG Price: $249.99 |
| 72 |
539109161 |
KEY 1/4 SQ X 1-1/2 Price: $2.99 |
| 73 |
574480601 |
SHIELD, HEAT BARRIER Price: $21.99 |
| 74 |
575244501 |
MUFFLER.DIESEL.KUBOTA Price: $599.99 |
| 75 |
575699401 |
SPACER, RUBBER Price: $17.99 |
| 76 |
539110656 |
WASH 1/2 X 1 SPRG STL & NEOP Price: $3.99 |
| 77 |
596919401 |
Pins This part replaces 510090101. Price: $4.99 |
| 78 |
522705201 |
RING, E, 7/16 Price: $2.99 |
| 79 |
575804901 |
HOSE, VENT Price: $16.99 |
| 80 |
575244503 |
PIPE, MANIFOLD, DIESEL Price: $229.99 |
| 81 |
539116400 |
TERMINAL COVER-SM Price: $2.99 |
