| Ref | Part Number | Description |
|---|
| 1 |
104-4890 |
PISTON PUMP ASM Price: $2,386.28 |
| 1 |
490073 |
SCREW, COVER MOUNTING Price: Call Us |
| 2 |
223765 |
COVER, AIR CLEANER Price: Call Us |
| 2 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 3 |
323-8 |
SCREW-HH Price: $1.20 |
| 3 |
399959 |
FILTER, AIR Price: Call Us |
| 4 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 4 |
94018 |
SCREW, AIR CLEANER Price: Call Us |
| 5 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 5 |
490074 |
BASE, AIR CLEANER Price: Call Us |
| 6 |
271935 |
GASKET, AIR CLEANER MOUNTING Price: Call Us |
| 6 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 7 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 7 |
492611 |
CARBURERTOR ASSEMBLY Price: Call Us |
| 8 |
223793 |
THROTTLE, CARBURETOR Price: Call Us |
| 8 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 9 |
93499 |
SCREW Price: Call Us |
| 9 |
95-3502 |
FITTING-ELBOW 90 Price: $87.71 |
| 10 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 10 |
93527 |
SCREW, MACHINE, ROUND HEAD Price: Call Us |
| 11 |
108-9008 |
HOSE ASM Price: $295.55 |
| 11 |
260575 |
SPRING, THROTTLE ADJUSTMENT Price: Call Us |
| 12 |
104-5486 |
HOSE Price: $109.79 |
| 12 |
490048 |
SHAFT AND LEVER THROTTLE Price: Call Us |
| 13 |
271853 |
WASHER, THROTTLE SHAFT, FOAM Price: Call Us |
| 13 |
32128-54 |
NUT-HF Price: $5.25 |
| 14 |
398970 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 14 |
99-3624 |
SHAFT-PIVOT, IDLER Price: $67.19 |
| 15 |
262270 |
LINK, THROTTLE Price: Call Us |
| 15 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 16 |
271936 |
GASKET, INTAKE ELBOW MOUNTING Price: Call Us |
| 16 |
32128-21 |
NUT-HF Price: $0.39 |
| 17 |
280720 |
BELL CRANK Price: Call Us |
| 17 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 18 |
231520 |
SCREW, SHOULDER Price: Call Us |
| 18 |
323-10 |
SCREW-HH Price: $0.89 |
| 19 |
231533 |
VALVE, NEEDLE Price: Call Us |
| 19 |
74-1810 |
WASHER Price: $0.39 |
| 20 |
139-6031 |
PULLEY-IDLER This part replaces 107-7834. Price: $121.38 |
| 20 |
491177 |
VALVE AND SHAFT GROUP, CHOKE Price: Call Us |
| 21 |
270382 |
WASHER, FOAM Price: Call Us |
| 22 |
115-3498 |
SPRING KIT This part replaces 100-4844. Price: $27.21 |
| 22 |
221839 |
WASHER, BRASS Price: Call Us |
| 23 |
137-1653 |
IDLER ARM ASM This part replaces 99-3623-03. Price: $37.07 |
| 23 |
26336 |
SPRING, NEEDLE VALVE Price: Call Us |
| 24 |
223789 |
PLUG, WELCH Price: Call Us |
| 24 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 25 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 25 |
391813 |
FUEL PIPE AND CLIP ASSEMBLY Price: Call Us |
| 26 |
323-19 |
SCREW-HH Price: $1.70 |
| 27 |
220352 |
PLUG, WELCH Price: Call Us |
| 27 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 28 |
221377 |
CAP, SPRING Price: Call Us |
| 28 |
99-3436-0P |
SUPPORT-PUMP This part replaces 99-3436-03. Price: $150.02 |
| 29 |
262328 |
SPRING, FUEL PUMP DIAPHRAGM Price: Call Us |
| 29 |
99-3440 |
SPACER Price: $6.78 |
| 30 |
270026 |
DIAPHRAGM Price: Call Us |
| 30 |
33114-060 |
SCREW-HH Price: $0.88 |
| 31 |
210959 |
COVER, DIAPHRAGM Price: Call Us |
| 31 |
87-8640 |
WASHER-FLAT Price: $0.68 |
| 32 |
105-1214 |
HOSE-HYD Price: $327.26 |
| 32 |
93265 |
PIN, DIAPHRAGM COVER Price: Call Us |
| 33 |
93141 |
SCREW, DIAPHRAGM Price: Call Us |
| 33 |
95-8933-0P |
PLATE - PUMP MOUNT *B This part replaces 95-8933-03. Price: $105.46 |
| 34 |
93543 |
SCREW, SEMS, HEX HEAD Price: Call Us |
| 34 |
95-8941 |
SPACER-MOUNT, PUMP Price: $8.87 |
| 35 |
490589 |
SCREW AND COLLAR Price: Call Us |
| 35 |
99-3620 |
PULLEY-3V, PUMP Price: $317.63 |
| 36 |
223813 |
CRANK, BELL Price: Call Us |
| 36 |
32-1140 |
DISCONTINUED This part replaces 321-13. Price: $2.04 |
| 37 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
490507 |
RETAINER, LINK Price: Call Us |
| 38 |
100-4813 |
BUSHING-LOCK, TAPER Price: $37.51 |
| 38 |
262279 |
ROD, SPEED CONTROL Price: Call Us |
| 39 |
220982 |
WASHER Price: Call Us |
| 39 |
99-3619 |
BELT-3V Price: $61.56 |
| 40 |
70-2041 |
TRIM Price: $5.30 |
| 40 |
93357 |
SCREW, SEMS, CARBURETOR MOUNTING Price: Call Us |
| 41 |
280715 |
KNOB, CONTROL Price: Call Us |
| 41 |
353-949 |
O-RING Price: $3.49 |
| 42 |
108-9036 |
HYD GEAR PUMP ASM This part replaces 100-1646. Price: $1,277.80 |
| 42 |
490649 |
PANEL, CONTROL Price: Call Us |
| 43 |
262359 |
LINK, CHOKE Price: Call Us |
| 43 |
323-7 |
SCREW-HH Price: $0.65 |
| 44 |
262470 |
LINK, CONTROL Price: Call Us |
| 44 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 45 |
126-1963 |
BUSHING-PIVOT This part replaces 99-3631. Price: $6.69 |
| 45 |
93572 |
SCREW Price: Call Us |
| 46 |
262282 |
SPRING, GOVERNOR Price: Call Us |
| 46 |
99-3625 |
SPACER-ARM, IDLER Price: $9.01 |
| 47 |
100-4852 |
WASHER-HARDENED Price: $4.63 |
| 47 |
491577 |
LEVER, BRACKET ASSEMBLY Price: Call Us |
| 48 |
72-4170 |
WASHER-SPCL Price: $27.89 |
| 48 |
93491 |
RIVET, GOVERNOR CONTROL LEVER MOUNTING Price: Call Us |
| 49 |
222962 |
BUSHING, GOVERNOR LEVER, FLAT Price: Call Us |
| 50 |
223455 |
LEVER, GOVERNOR CONTROL Price: Call Us |
| 51 |
396847 |
SWITCH, STOP Price: Call Us |
| 52 |
94409 |
SCREW, SEMS, TANK BRACKET MNT. Price: Call Us |
| 53 |
280321 |
RACK, GEAR CONTROL Price: Call Us |
| 54 |
490554 |
TAMK ASSEMBLY, FUEL Price: Call Us |
| 55 |
490075 |
CAP, FUEL TANK Price: Call Us |
| 56 |
271928 |
GASKET, FUEL TANK MOUNTING Price: Call Us |
| 57 |
223786 |
CLAMP BREATHER TUBE Price: Call Us |
