| Ref | Part Number | Description |
|---|
| 1 |
147-0062 |
RADIATOR/OIL COOLER ASM This part replaces 138-7420. Price: $1,865.13 |
| 2 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 3 |
139-6232 |
SHROUD-COOLER ASM Price: $330.98 |
| 4 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 6 |
139-6229 |
STRAP-COOLER Price: $37.90 |
| 7 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 8 |
1-807512 |
BOLT-CARR Price: $1.29 |
| 9 |
104-7201 |
NUT-HF Price: $0.69 |
| 10 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
138-4410 |
SEAL-FOAM Price: $9.65 |
| 13 |
138-4411 |
SEAL-FOAM Price: $9.11 |
| 14 |
138-4453 |
FOAM-RADIATOR Price: $11.09 |
| 15 |
138-4454 |
FOAM-RADIATOR, SIDE Price: $11.87 |
| 16 |
138-4461-0P |
BRACKET-SHROUD RETAINER Price: Call Us |
| 17 |
139-6230 |
BRACKET-BOTTLE MOUNT Price: $51.70 |
| 18 |
106-1126 |
HOSE-FUEL Price: $10.06 |
| 19 |
108-1393 |
STRIP-FOAM Price: $17.19 |
| 20 |
MSC14544 |
GROMMET Price: $3.31 |
| 22 |
140-5841 |
TRIM-COOLER Price: $3.25 |
| 23 |
130-9182 |
FOAM-RADIATOR, SHORT Price: $7.81 |
