| Ref | Part Number | Description |
|---|
| 1 |
530057893 |
Knob-Choke Price: $3.99 |
| 2 |
530057908 |
Spring-Ign. Switch Price: $2.99 |
| 3 |
530057891 |
Lever-Ign. Switch Price: $4.99 |
| 4 |
530016080 |
Screw Price: $1.99 |
| 5 |
530071888 |
Kit-Trigger/Lockout Price: $6.99 |
| 6 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 7 |
530069247 |
Kit-Fuel Line (Small) Price: $3.69 |
| 8 |
530095646 |
Assy-Fuel Pick-up This part replaces 530095649. Price: $2.69 |
| 9 |
530023877 |
Fitting-Fuel line Price: $1.99 |
| 10 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 10 |
98-7791 |
VALVE-INLET Price: $44.20 |
| 11 |
530057905 |
Assy-Clutch Drum 3/8" Price: $13.99 |
| 12 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 13 |
530057907 |
Assy-Clutch Price: $6.99 |
| 14 |
530016419 |
Washer-Large Clutch Price: $1.99 |
| 15 |
577858501 |
FUEL CAP ASSY W/RET This part replaces 530047192. Price: $4.99 |
| 16 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 17 |
530015922 |
Nut-"U" type speed Price: $1.99 |
| 18 |
530057937 |
Assy-Flywheel Price: $22.99 |
| 19 |
530057911 |
Shield-Heat Price: $2.99 |
| 20 |
114-5099 |
VALVE-EXHAUST This part replaces 100-9281. Price: $46.81 |
| 20 |
530015127 |
Washer-Flywheel Price: $1.99 |
| 21 |
530016134 |
Nut-Flywheel Price: $1.99 |
| 22 |
530015920 |
Screw Price: $1.99 |
| 23 |
530057890 |
Pulley-Starter Price: $5.99 |
| 24 |
545008013 |
Kit-Starter Spring This part replaces 530042095. Price: $3.49 |
| 25 |
530058810 |
Housing-Fan Price: $11.99 |
| 26 |
530056402 |
Handle-Starter Price: $2.99 |
| 27 |
530069232 |
Kit-Rope Price: $3.99 |
| 28 |
530016432 |
Screw Price: $1.99 |
| 29 |
530016080 |
Screw Price: $1.99 |
| 30 |
530058786 |
Assy-Oil Vent Price: $2.99 |
| 30 |
98-7793 |
SPRING-VALVE Price: $21.84 |
| 31 |
530057236 |
Assy-Oil Cap w/ret. Price: $5.99 |
| 32 |
530057897 |
Handguard Price: $7.99 |
| 33 |
530016416 |
Spring-Handguard Price: $1.99 |
| 34 |
530058870 |
Assy-Chassis This part replaces 530058863. Price: $49.99 |
| 35 |
530071893 |
Kit-Chainbrake Price: $17.99 |
| 36 |
530016432 |
Screw Price: $1.99 |
| 37 |
530016133 |
Bolt-Bar Price: $1.99 |
| 38 |
530057910 |
Plate-Bar Price: $1.99 |
| 39 |
530015917 |
Nut-Bar Price: $0.99 |
| 40 |
98-7794 |
RETAINER-SPRING, VALVE Price: $13.61 |
| 42 |
530015826 |
Pin-Bar Adjust Price: $1.99 |
| 43 |
530038593 |
Retainer-Bar Adjust Price: $0.99 |
| 44 |
952051211 |
Accy-16" Chain Price: Call Us |
| 45 |
952044370 |
Accy-16" Bar Price: Call Us |
| 47 |
530016432 |
Screw Price: $1.99 |
| 48 |
530057888 |
Handle-Front Price: $14.99 |
| 50 |
530057924 |
Assy-Oil Pick Up Price: $2.99 |
| 50 |
98-7795 |
COLLET-SPRING, VALVE Price: $6.71 |
| 51 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 52 |
530057931 |
Assy-Oil Pump Price: $10.99 |
| 60 |
98-7796 |
SEAL-STEM, VALVE Price: $7.73 |
| 70 |
98-7797 |
CAP-VALVE Price: $5.22 |
| 80 |
107-0134 |
SHAFT-ARM, ROCKER Price: $109.11 |
| 80 |
98-7798 |
ROCKER ARM SHAFT ASM Price: $200.60 |
| 85 |
107-0135 |
SCREW-SET Price: $0.80 |
| 90 |
98-7884 |
BOLT Price: $0.42 |
| 100 |
98-7800 |
BRACKET-ARM, ROCKER Price: $28.90 |
| 110 |
98-7801 |
STUD Price: $4.42 |
| 120 |
98-7534 |
NUT Price: $0.48 |
| 130 |
105-2893 |
WASHER-SPRING Price: $0.48 |
| 140 |
98-7536 |
WASHER-PLAIN Price: $0.28 |
| 150 |
98-7805 |
PIN-SPRING Price: $0.95 |
| 160 |
98-7806 |
WASHER Price: $0.24 |
| 170 |
98-7807 |
SPRING-ARM, ROCKER Price: $0.85 |
| 175 |
98-7808 |
CLIP-CIR., EXTERNAL Price: $0.17 |
| 180 |
98-7660 |
WASHER-PLAIN Price: $0.28 |
| 185 |
105-2893 |
WASHER-SPRING Price: $0.48 |
| 190 |
98-7809 |
ROCKER ARM ASM Price: $39.80 |
| 200 |
98-7810 |
SCREW-ADJUSTING Price: $2.60 |
