| Ref | Part Number | Description |
|---|
| 1 |
76-5610 |
PINION-OUTPUT Price: $436.03 |
| 3 |
76-5630 |
GEAR-SPUR Price: $109.36 |
| 3 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 4 |
76-5640 |
GASKET-CASE & COVER Price: $57.02 |
| 5 |
532164329 |
PIN.SPIROL.FLARED Price: $3.99 |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 6 |
95-7236 |
PIN - DOWEL This part replaces 76-5660. Price: $3.56 |
| 7 |
76-5670 |
SEAL-OIL Price: $27.67 |
| 7 |
872110404 |
BOLT Price: $7.99 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $3.99 |
| 8 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 8A |
76-5650 |
WASHER-THRUST Price: $4.91 |
| 9 |
76-5690 |
WASHER-THRUST Price: $7.71 |
| 9 |
817021008 |
SCREW This part replaces 532086777. Price: $3.99 |
| 10 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 10 |
76-5700 |
BEARING-THRUST Price: $21.09 |
| 11 |
76-5710 |
PLUG-DRAIN, MAGNETIC Price: $9.38 |
| 12 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 12 |
76-5720 |
SCREW-HWHTF Price: $3.07 |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 14 |
532156117 |
SPACER-SPLIT.327 X .42 Price: $4.99 |
| 14 |
76-6040 |
PLUG-PIPE Price: $3.65 |
| 15 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 15 |
92-0639 |
TRANSAXLE CASE ASM Price: $1,083.47 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $59.99 |
| 16 |
76-5760 |
TRANSAXLE COVER ASM Price: $1,125.72 |
| 17 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 17 |
92-0642 |
GEAR-OUTPUT Price: $362.07 |
| 18 |
532131691 |
SPACER SPLIT Price: $4.99 |
| 18 |
76-5780 |
GEAR-SPUR Price: $158.15 |
| 19 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 19 |
92-0644 |
GEAR-CLUSTER Price: $570.98 |
| 20 |
92-0641 |
SHAFT-COUNTER Price: $258.16 |
| 21 |
92-0645 |
SHIFTER-GEAR & SHAFT Price: $633.78 |
| 22 |
76-5820 |
SCREW-HHF Price: $4.40 |
| 23 |
532005014 |
RIM 2.75 X 8.0 X 1"ID.TILLER Price: $139.99 |
| 23 |
532005015 |
TIRE.16X4-8.CHEVRON.TILLER Price: $99.99 |
| 23 |
532065139 |
VALVE STEM LT This part replaces 532124718. Price: $5.99 |
| 23 |
76-5830 |
BALL-STEEL Price: $3.25 |
| 24 |
532004929 |
RIVET TI Price: $5.99 |
| 24 |
95-7202 |
SPRING This part replaces 76-5840. Price: $5.26 |
| 25 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 25 |
76-5850 |
DISCONTINUED Price: Call Us |
| 26 |
532442960 |
GUARD.BELT.TILLER.8HP.ORANGE Price: $59.99 |
| 26 |
76-5860 |
BEARING-NEEDLE Price: $48.93 |
| 27 |
532138399 |
BELT, DRIVE Price: $44.99 |
| 27 |
76-5870 |
BEARING-NEEDLE Price: $46.51 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $14.99 |
| 28 |
92-0640 |
DISCONTINUED Price: Call Us |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532159229. Price: $12.99 |
| 30 |
76-5890 |
RING-RETAINING Price: $6.21 |
| 32 |
532139401 |
SHAFT, IDLER ARM Price: $12.99 |
| 35 |
76-5900 |
FORK-SHIFT Price: $38.25 |
| 36 |
92-0647 |
ROD-SHIFT, HI-LOW Price: $12.09 |
| 37 |
532004368 |
SHEAVE, ENGINE Price: $13.99 |
| 37 |
92-0643 |
DISCONTINUED Price: Call Us |
| 38 |
76-5930 |
DRIVE BLOCK Price: $34.87 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $4.99 |
| 39 |
76-5940 |
DRIVE PIN Price: $15.24 |
| 40 |
76-5950 |
DISCONTINUED Price: Call Us |
| 41 |
76-5960 |
CARRIER-DIFFERENTIAL Price: $278.78 |
| 42 |
104-0195 |
BEARING-BALL, HI-CAP This part replaces 92-0646. Price: $63.13 |
| 42 |
532106160 |
O-RING TI Price: $3.99 |
| 43 |
76-5980 |
SCREW-HHF Price: $13.37 |
| 44 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 45 |
76-5990 |
CARRIER-DIFFERENTIAL Price: $290.15 |
| 47 |
76-6000 |
DISCONTINUED Price: Call Us |
| 49 |
76-6010 |
SPACER Price: $18.94 |
| 50 |
76-6020 |
DISCONTINUED Price: Call Us |
| 51 |
76-6030 |
SEAL-OIL Price: $17.61 |
| 52 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 54 |
532104214 |
NUT TI Price: $3.99 |
| 62 |
874930572 |
BOLT 5/16-18X4 1/2 Price: $2.99 |
| 63 |
532175797 |
Bracket Asm Guard Price: Call Us |
| 64 |
874770508 |
BOLT Price: $2.99 |
