| Ref | Part Number | Description |
|---|
| 1 |
233-42 |
KNOB Price: $12.88 |
| 2 |
94-7060-03 |
THROTTLE ASM ASM This part replaces 94-7060. Price: $101.95 |
| 3 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 4 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 5 |
99-0542 |
SCREW Price: $0.10 |
| 6 |
94-7064 |
PLATE-THROTTLE Price: $12.88 |
| 7 |
94-7063-03 |
SPACER-BEARING MOUNT This part replaces 94-7063. Price: $35.14 |
| 8 |
192706 |
Rod Shift Price: Call Us |
| 8 |
3290-450 |
WASHER-BELLEVILLE Price: $2.51 |
| 9 |
3256-15 |
WASHER-FLAT Price: $0.68 |
| 10 |
3296-45 |
NUT-HEX Price: $3.79 |
| 10 |
76020416 |
Pin Cotter 1/8 X 1 Price: Call Us |
| 11 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 12 |
93-0073 |
CABLE - THROTTLE Price: $23.39 |
| 13 |
92-0477 |
CLAMP-CABLE Price: $8.69 |
| 14 |
10040400 |
Washer Lock 1/4 Price: Call Us |
| 14 |
3290-360 |
SCREW-HH Price: $4.34 |
| 15 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 15 |
74490544 |
Bolt Hex FLGHD 5/16-18 Gr. 5 unc Price: Call Us |
| 16 |
73800500 |
Nut Lock Hex w/ins 5/16-18 unc Price: Call Us |
| 16 |
94-8535 |
PANEL ASM Price: $149.31 |
| 17 |
92-8531 |
BOOT-SWITCH Price: $24.27 |
| 18 |
30953 |
SWITCH - VALVE Price: $33.16 |
| 19 |
73800600 |
Nut Lock Hex w/wsh 3/8-16 unc Price: Call Us |
| 19 |
92-0250 |
TOGGLE SWITCH Price: $51.53 |
| 20 |
3290-134 |
SCREW Price: $0.27 |
| 21 |
140845 |
Knob Price: Call Us |
| 21 |
94-7087 |
PAD Price: $75.02 |
| 22 |
169498 |
Rod Brake Price: Call Us |
| 22 |
94-7178 |
SEAL-FOAM, CONSOLE Price: $15.58 |
| 23 |
94-7081 |
DISCONTINUED Price: Call Us |
| 24 |
73350600 |
Nut Price: Call Us |
| 24 |
94-7141 |
GROMMET Price: $2.63 |
| 25 |
106888X |
Spring Rod Brake Price: Call Us |
| 25 |
87-0450 |
DECAL-CAUTION, BRAKING Price: $33.40 |
| 26 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 26 |
3217-5 |
NUT-HEX Price: $0.25 |
| 27 |
321-8 |
SCREW-HH Price: $0.34 |
| 27 |
76020412 |
Pin Cotter 1/8 x 3/4 Price: Call Us |
| 28 |
175765 |
Rod Brake Parking Price: Call Us |
| 28 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 29 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 29 |
71673 |
Cap Brake Parking Price: Call Us |
| 30 |
174973 |
Bracket Transmission Price: Call Us |
| 30 |
94-7142 |
PANEL-FOAM Price: $39.15 |
| 31 |
325-6 |
SCREW-HH Price: $1.42 |
| 32 |
3217-6 |
NUT-HEX Price: $1.19 |
| 32 |
74760512 |
Bolt Hex Hd 5/16-18 unc x 3/4 Price: Call Us |
| 33 |
3217-26 |
NUT-HEX Price: $0.25 |
| 34 |
175578 |
Shaft Foot Pedal Price: Call Us |
| 34 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 35 |
120183X |
Bearing Nylon Price: Call Us |
| 35 |
94-7242 |
SWITCH Price: $71.33 |
| 36 |
19211616 |
Washer Price: Call Us |
| 37 |
1572H |
Pin Roll Price: Call Us |
| 38 |
179114 |
Pulley Idler Composite Price: Call Us |
| 39 |
72110622 |
Bolt Price: Call Us |
| 41 |
175556 |
Keeper Belt Idler Price: Call Us |
| 47 |
127783 |
Pulley Idler V-Belt Price: Call Us |
| 48 |
154407 |
Bellcrank Clutch Grnd Drustl Price: Call Us |
| 49 |
123205X |
Retainer Belt Price: Call Us |
| 50 |
72110612 |
Bolt Carr. Sh. 3/8-16 x 1-1/2 Gr. 5 Price: Call Us |
| 51 |
73680600 |
Nut Price: Call Us |
| 52 |
73680500 |
Nut Crownlock 5/16-28 Price: Call Us |
| 53 |
199652 |
Link Clutch Price: Call Us |
| 55 |
105709X |
Spring Return Clutch Price: Call Us |
| 56 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 57 |
140294 |
V-Belt Drive Price: Call Us |
| 59 |
169691 |
Keeper Belt Center Price: Call Us |
| 61 |
17120614 |
Screw 3/8-16 x .875 Price: Call Us |
| 62 |
8883R |
Cover Pedal Price: Call Us |
| 63 |
175410 |
Engine Pulley Price: Call Us |
| 64 |
173937 |
Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 THr. Price: Call Us |
| 65 |
10040700 |
Washer Price: Call Us |
| 66 |
154778 |
Keeper Belt Engine Hydro Price: Call Us |
| 69 |
142432 |
Screw Hex wsh HiLo 1/4 x 1/2 unc Price: Call Us |
| 70 |
134683 |
Guide Belt Mower Drive RH Price: Call Us |
| 71 |
169183 |
Strap Torque, LH Price: Call Us |
| 73 |
169182 |
Strap Torque, RH Price: Call Us |
| 74 |
137057 |
Spacer Axle Price: Call Us |
| 75 |
121749X |
Washer 25/32 x 1 1/4 x 16 Ga. Price: Call Us |
| 76 |
12000001 |
Ring, E Price: Call Us |
| 77 |
123583X |
Key Square Price: Call Us |
| 78 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 81 |
165596 |
Shaft Asm Cross Price: Call Us |
| 82 |
165711 |
Spring Torsion Price: Call Us |
| 83 |
19171216 |
Washer 17/32 x 3/4 x 16 Ga. Price: Call Us |
| 84 |
169843 |
Link Transaxle Price: Call Us |
| 89 |
192056X428 |
Console Shift Price: Call Us |
| 95 |
170201 |
Control Asm Bypass Hydro Price: Call Us |
| 96 |
4497H |
Retainer Spring 1" Price: Call Us |
| 103 |
73940800 |
Nut, Hex Jam Top Lock 1/2-20 unf Price: Call Us |
| 112 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga. Price: Call Us |
| 116 |
72140608 |
Bolt 3/8-16 x 1 Price: Call Us |
| 120 |
73900600 |
Bolt Hex 3/8-16 x 1-1/2 Price: Call Us |
| 150 |
175456 |
Spacer Retainer Price: Call Us |
| 151 |
19133210 |
Washer 13/32 x 2 x 10 Price: Call Us |
| 156 |
166002 |
Washer 5/16 x 1.0 x 1.25 Price: Call Us |
| 158 |
165589 |
Bracket Shift Mount Price: Call Us |
| 159 |
183900 |
Hub Tapered Flange Shift Price: Call Us |
| 161 |
72140406 |
Bolt Rdhd Sqnk 1/4-20 x 3/4 Gr. 5 Price: Call Us |
| 162 |
73680400 |
Nut Crownlock 1/4-20 unc Price: Call Us |
| 163 |
74780416 |
Bolt Hex Fin 1/4-20 x 1 Price: Call Us |
| 165 |
165623 |
Bracket Pivot Lever Price: Call Us |
| 166 |
17490510 |
Screw 5/16-18 x 1.0 x .125 Price: Call Us |
| 168 |
165492 |
Bolt Shoulder 5/16-18 x .561 Price: Call Us |
| 169 |
165580 |
Plate Fastening Price: Call Us |
| 197 |
169613 |
Nyliner Snap-In 5/8 Price: Call Us |
| 198 |
169593 |
Washer Nyliner 7/8 ID x .105 HYD Price: Call Us |
| 199 |
169612 |
Bolt Shoulder 5/16-18 unc Price: Call Us |
| 200 |
72140508 |
Bolt Rdhd Sqnk 5/16-18 unc x 1 Price: Call Us |
| 202 |
72110614 |
Bolt RdHd 3/8-16 unc x 1-1/2 Gr. 5 Price: Call Us |
| 205 |
19171616 |
Washer 17/32 x 1 x 16 Ga. Price: Call Us |
| 212 |
145212 |
Nut Hex flange Lock Price: Call Us |
