HANDLE & CONTROLS
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 139-8757 | SUBFRAME ASM This part replaces 110-4221-01. Price: $3,321.21 |
| 1 | 537424513 | HANDLE SYSTEM ASSY Price: $49.99 |
| 2 | 3290-384 | PIN-LYNCH Price: $18.43 |
| 2 | 502654101 | Price: Call Us |
| 3 | 110-4314 | PIN-LINK, CAT 2 Price: $72.32 |
| 3 | 110-4315 | PIN-LINK, CAT 1 Price: $42.75 |
| 3 | 503221013 | NUT Price: $3.99 |
| 4 | 104-8322 | WASHER-HARDENED Price: $23.22 |
| 5 | 3219-18 | NUT-HEX Price: $3.26 |
| 5 | 537419001 | STOP BUTTON Price: $7.99 |
| 6 | 506497701 | THROTTLE CONTROL Price: $6.99 |
| 7 | 110-4440 | PAD Price: $16.16 |
| 7 | 537174201 | SPRING Price: $4.99 |
| 8 | 3234-17 | SCREW-HHF Price: $0.72 |
| 8 | 537160703 | STARTER THROTTLE LOCK This part replaces 537160701. Price: $4.99 |
| 9 | 506497701 | THROTTLE CONTROL Price: $6.99 |
| 9 | 92-1298 | PIN-LYNCH Price: $2.27 |
| 10 | 537174301 | SPRING Price: $3.99 |
| 10 | 92-1233 | PIN-CLEVIS Price: $15.45 |
| 11 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 12 | 503216618 | SCREW Price: $3.99 |
| 13 | 503200782 | SCREW IHSCFM This part replaces 503200735. Price: $3.99 |
| 14 | 503724309 | HANDLE Price: $49.99 |
| 15 | 731231401 | NUT Price: $1.99 |
| 16 | 537172801 | HANDLE Price: $14.99 |
| 17 | 503200245 | SCREW Price: $3.99 |
| 20 | 544020901 | CLAMP Price: $12.99 |
| 21 | 502211201 | GROMMET Price: $3.99 |
| 22 | 503216618 | SCREW Price: $3.99 |
| 23 | 502531602 | Price: Call Us |
| 24 | 537173901 | THROTTLE WIRE Price: $27.99 |
