| Ref | Part Number | Description |
|---|
| 1 |
130-7105 |
FUEL TANK ASM Price: $532.81 |
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532424068. Price: $159.99 |
| 2 |
127-8971-03 |
COVER-TANK, FUEL Price: $8.27 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 3 |
144-6210 |
PUMP-FUEL This part replaces 121-5641. Price: $157.52 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
131-9550-03 |
BRACKET-TANK, FUEL TANK Price: $279.64 |
| 5 |
108-1605 |
BUMPER-RECESS Price: $10.02 |
| 6 |
107-4543 |
CLAMP Price: $13.47 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 10 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 11 |
110-6186 |
HOSE-FUEL Price: $15.70 |
| 12 |
98-1375 |
SCREW-HWH Price: $1.45 |
| 13 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 14 |
3230-3 |
SCREW-CARR Price: $0.53 |
| 15 |
125-2921 |
FITTING-FUEL Price: $13.96 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
