| Ref | Part Number | Description |
|---|
| 1 |
GW-9362 |
Spring Pin, 1/8" Price: $3.82 |
| 2 |
736-0326 |
Flat Washer,.510 x 1.00 This part replaces 936-0326. Price: $3.89 |
| 3 |
GW-9934 |
Shoulder Washer, 1.25 x .50 x .25 Price: $13.73 |
| 4 |
GW-9932 |
Disc Spring Washer Price: $21.54 |
| 5 |
GW-2628 |
Wheel Speed Shift Lever Price: $124.90 |
| 6 |
1902240 |
Knob Price: $20.45 |
| 7 |
GW-9317 |
Cotter Pin, 3/32" x 1" Price: $3.22 |
| 8 |
GW-1033 |
Swivel Price: $13.56 |
| 9 |
736-0275 |
FLAT WASHER This part replaces 936-0275. Price: $5.99 |
| 10 |
714-04048 |
Hair Pin Cotter Price: $7.04 |
| 11 |
912-0158 |
Hex Locknut, 5/16"-18 Price: $2.83 |
| 12 |
710-0514 |
Hex Head Screw, 3/8"-16 x 1" Price: $3.78 |
| 13 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces 936-0169. Price: $3.33 |
| 14 |
736-3050 |
Flat Washer, .406 x .810 x .051 Price: $3.90 |
| 15 |
GW-1113-1099 |
Bushing Spacer, .5 x .375 x .3 Price: $4.53 |
| 16 |
GW-9120 |
Retaining Ring Price: $5.94 |
| 17 |
GW-2102A |
BELT ADJUSTMENT BLOCK This part replaces GW-2102. Price: $43.50 |
| 18 |
GW-2100 |
Belt Adjustment Rod Price: $11.28 |
| 19 |
712-3012A |
HEX NUT This part replaces 912-3012. Price: $11.49 |
| 20 |
710-0539 |
Hex Head Screw, 3/8"-24 x 1.75 Price: $3.95 |
| 21 |
756-04171 |
Reverse Disc Price: $58.85 |
| 22 |
GW-9245 |
Forward Drive Belt Price: $21.83 |
| 23 |
619-04124 |
Engine Power Take-off Pulley Price: $135.20 |
| 24 |
736-04187 |
Flat Washer, .766 x 1.0 x .062 Price: $4.36 |
| 24 |
736-04192 |
Flat Washer, .766 x 1.0 x .031 Price: $5.94 |
| 25 |
GW-9303 |
Engine Pulley Key, 3/16"x 2-1/2" Price: $3.22 |
| 26 |
710-0376 |
Hex Head Screw, 5/16"-18 x 1" Price: $3.66 |
| 27 |
712-3010 |
HEX NUT 5/16-18 This part replaces 912-3010. Price: $3.89 |
| 28 |
GW-1034A |
Engine Mounting Bar Price: $41.06 |
| 29 |
GW-9147 |
Thread Protector Plug Price: $7.05 |
| 30 |
710-0672 |
Hex Head Screw, 5/16-24 x 1.25 Price: $3.85 |
| 31 |
936-0119 |
Lockwasher, 5/16" Price: $4.29 |
| 32 |
719-04222-0637 |
Motor Mount Price: $274.62 |
| 33 |
736-3052 |
Flat Washer, .406 x 1.0 x .105 Price: $4.02 |
| 34 |
710-05289 |
Hex Screw, 1/4"-20 x 1-1/2" Price: $4.83 |
| 35 |
634-04230-0662 |
Rim Assembly Price: $77.28 |
| 35 |
734-0808A |
Tire, 16.2 x 4.6 Price: $108.82 |
| 35 |
934-04231 |
Wheel Assembly, 16 x 4.6 x 8" Price: $226.23 |
| 36 |
712-04064 |
Hex Flange Nut, 1/4"-20 Price: $3.64 |
