| Ref | Part Number | Description |
|---|
| 1 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 2 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 3 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 4 |
94-5033-03 |
BRACKET-SUPPORT, CYLINDER This part replaces 94-5033. Price: $182.59 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 5 |
92-7905 |
SWITCH AND BRACKET ASM Price: $293.34 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
3249-3 |
SCREW-PRH Price: $0.34 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 10 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 11 |
282-4 |
SHACKLE Price: $32.98 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $22.99 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 12 |
61-3830 |
CHAIN Price: $14.52 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 13 |
94-5010 |
PIN-ACTUATOR, SWITCH Price: $101.45 |
| 14 |
94-5011 |
SPRING-COMPRESSION Price: $18.13 |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
532127218 |
FRONT LINK Price: $14.99 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 16 |
72-4190 |
PIN-GUIDE, CYLINDER Price: $79.12 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $3.99 |
| 17 |
84-8440 |
BUSHING Price: $49.87 |
| 18 |
321-43 |
CAPSCREW Price: $0.41 |
| 18 |
596433401 |
Nuts This part replaces 873680800. Price: $2.99 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 19 |
61-2450 |
HUB-LIFT V Price: $106.24 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
340-86 |
FITTING-TEE Price: $35.23 |
| 22 |
94-5031 |
HYD CYLINDER ASM Price: $830.71 |
| 23 |
283-78 |
PIN-CLEVIS Price: $9.25 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 24 |
93-6733-03 |
BRACKET-MOUNT, VALVE This part replaces 93-6733. Price: $15.62 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 25 |
93-6718 |
BLOCK-VALVE Price: $2,070.41 |
| 26 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 26 |
596917601 |
Pins This part replaces 876020308. Price: $1.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 27 |
93-6904 |
SPACER-TUBE, SPLIT Price: $1.07 |
| 28 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT This part replaces 532140302. Price: $5.99 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 32 |
93-6935 |
DISCONTINUED Price: Call Us |
| 33 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 34 |
93-6800 |
HOSE-HYD Price: $89.80 |
| 35 |
94-5009 |
HOSE ASM Price: $102.32 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 36 |
94-5008 |
HOSE ASM Price: $102.26 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 37 |
94-5007 |
DISCONTINUED Price: Call Us |
| 38 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 38 |
94-5006 |
HOSE ASM Price: $85.73 |
| 39 |
237-22 |
O-RING Price: $2.43 |
| 40 |
237-79 |
O-RING Price: $5.46 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
237-42 |
O-RING Price: $2.78 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 42 |
237-22 |
O-RING Price: $2.43 |
| 43 |
94-3424 |
BRACKET-MOUNT, SWITCH Price: $15.36 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
