| Ref | Part Number | Description |
|---|
| 1 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 2 |
104-9325 |
SPEEDOMETER KIT,RM5000 SERIES This part replaces 85-4420. Price: $449.92 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
3290-489 |
KNOB Price: $46.30 |
| 4 |
218-498 |
NUT-LOCK Price: $0.68 |
| 5 |
74-5950 |
LATCH-SWELL This part replaces 249-48. Price: $21.28 |
| 6 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 7 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 8 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 9 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 10 |
218-446 |
NUT-HEX Price: $6.09 |
| 11 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 12 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 13 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 14 |
75-0591 |
DISCONTINUED Price: Call Us |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
75-6270-03 |
COVER-BOX, CONTROL This part replaces 75-6270. Price: $87.82 |
| 16 |
75-1010 |
SWITCH-REEL Price: $84.90 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 19 |
27-2360 |
SWITCH Price: $46.56 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 23 |
85-4450 |
BRKT-FUSE BLOCK Price: $29.51 |
| 24 |
75-5740-03 |
BOX-CONTROL ASM This part replaces 75-5740. Price: $261.87 |
| 25 |
85-4480 |
KNOB Price: $16.02 |
| 26 |
321-39 |
SCREW-HH Price: $0.42 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 28 |
75-4710 |
HARNESS- WARNING LIGHTS Price: $55.53 |
| 29 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
218-535 |
NUT-HEX Price: $0.34 |
| 31 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-1794. Price: $2,183.63 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 33 |
321-4 |
SCREW-HH Price: $0.99 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 35 |
322-3 |
SCREW-HH Price: $0.79 |
| 35 |
583864502 |
Rods This part replaces 583864501. Price: $6.99 |
| 36 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 37 |
98-2195 |
JOYSTICK This part replaces 75-3420. Price: $520.10 |
| 38 |
111332 |
SWITCH This part replaces 218-590. Price: $10.99 |
| 39 |
3290-93 |
SCREW-HEAD, PAN Price: $0.25 |
| 40 |
3290-488 |
DISCONTINUED Price: Call Us |
| 41 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 42 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 43 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 44 |
104-4235 |
POTENTIOMETER ASM This part replaces 85-4470. Price: $260.80 |
| 45 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 46 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 47 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 50 |
85-4460 |
HOC SELECTOR DECAL Price: $7.84 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
2412-126 |
R-CLAMP This part replaces 2142-126. Price: $2.51 |
| 54 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 55 |
32128-33 |
NUT-HF Price: $0.25 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 56 |
85-4360 |
DISCONTINUED Price: Call Us |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 69 |
583404901 |
HAIRPIN.SOFT.ZINC.059X1.125 This part replaces 532423303. Price: $2.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
582404501 |
ARM.PIVOTING.TCRD.GEN2.5.BAGGE Price: $5.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop This part replaces 585658601. Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 587031401. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532197860 |
ROCKER.ASM.PEDAL.CONTR Price: $44.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
586606501 |
PEDAL.COVER.REVERSE.CRD.X498GY Price: $9.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 325 |
585668505 |
BRACKET TORQUE STRAP This part replaces 585668502. Price: $5.99 |
| 326 |
585670803 |
BRACKET TORQUE STRAP This part replaces 585670802. Price: $4.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
