| Ref | Part Number | Description |
|---|
| 1 |
981-0133B |
TOW BAR This part replaces 981-0133A. Price: $63.75 |
| 2 |
681-0134B-0637 |
TOW BAR BASE (POWDER BLACK) This part replaces 681-0134A-0637. Price: $73.39 |
| 3 |
710-3001 |
Hex Cap Screw, 3/8-16 x.88 Price: $6.20 |
| 4 |
711-0299 |
Clevis Pin,.625 x 2.4 Price: $32.19 |
| 5 |
911-0835 |
Clevis Pin,.50 x 4.62 Price: $11.12 |
| 6 |
712-04065 |
Flange Lock Nut, 3/8-16 Price: $3.68 |
| 7 |
732-0194 |
Spring Pin Price: $4.11 |
| 8 |
736-0133 |
Washer, Flat, .411 x 1.25 x .100 This part replaces 936-0133. Price: $4.67 |
| 9 |
981-04006-0638 |
CHUTE ASSEMBLY (UPPER) (MTD RED) This part replaces 681-04006-0638. Price: $190.10 |
| 10 |
681-04117A-0638 |
LOWER CHIPPER CHUTE (MTD RED) This part replaces 681-04117-0638. Price: $137.05 |
| 11 |
710-0106 |
Hex Cap Screw, 1/4-20 x 1.25 Price: $3.66 |
| 12 |
710-3013 |
Screw, 1/4-20 x .50 Price: $4.02 |
| 13 |
712-3010 |
HEX NUT 5/16-18 This part replaces 912-3010. Price: $3.89 |
| 14 |
712-04064 |
Flange Lock Nut 1/4-20 Price: $3.64 |
| 15 |
714-0104 |
Hairpin Clip This part replaces 914-0104. Price: $3.90 |
| 16 |
728-0175 |
Pop Rivet Price: $4.04 |
| 17 |
932-0306A |
Compression Spring,.531 x 1.75 Price: $7.69 |
| 18 |
735-0249A |
Chute Flap Price: $21.78 |
| 19 |
736-0140 |
Flat Washer, .385 x .62 x .063 This part replaces 936-0140. Price: $6.20 |
| 20 |
736-0242 |
Bell Washer.340 ID x.872 OD Price: $3.75 |
| 21 |
736-0451 |
Saddle Washer This part replaces 936-0451. Price: $3.75 |
| 22 |
947-04163 |
Lock Rod Price: $12.87 |
| 23 |
749-1004-0637 |
Chipper Chute Support This part replaces 749-1004-0638. Price: $41.22 |
| 24 |
981-04032 |
Chipper Chute Hinge Price: $11.28 |
| 25 |
781-0633 |
Chute Flap Strip Price: $9.09 |
| 26 |
710-0805A |
Hex Cap Screw, 5/16-18 x 1.50 Price: $3.75 |
| 27 |
749-04104-0637 |
Tube Support Price: $46.41 |
| 28 |
681-0184C-0638 |
Frame Assembly Price: $103.12 |
| 29 |
710-0502A |
Hex Sems Screw, 3/8-16 x 1.25 Price: $5.71 |
| 30 |
736-0170 |
SPECIAL WASHER Not Available This part replaces 936-0170. Price: |
| 31 |
726-0214 |
Push Cap, 5/8 Price: $9.11 |
| 32 |
934-04009 |
Wheel, 10 x 4 x 4 Not Available Price: |
| 33 |
950-0786 |
Spacer, .64 x .88 x .38 Price: $6.28 |
| 34 |
738-0813 |
Axle, 22.47" Price: $46.13 |
| 35 |
937-0195 |
Elbow Fitting Price: $14.91 |
| 36 |
726-0233 |
Push Nut,.25ID x.50OD Price: $3.93 |
| 38 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 39 |
710-0809 |
Hex Cap Screw, 1/4-20 x 1.250 Price: $6.37 |
