| Ref | Part Number | Description |
|---|
| 1 |
547745901 |
KIT.SVC.DECK.WELD.46.TEX_428 This part replaces 532442382. Price: $449.99 |
| 1 |
98-7342 |
INSIDE ARM ASM Price: $693.49 |
| 2 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 3 |
325-20 |
SCREW-HH Price: $6.29 |
| 4 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 4 |
69-8790-01 |
PLATE-REINFORCING Price: $21.41 |
| 5 |
98-4435 |
RUBBER MOUNT ASM This part replaces 69-9700. Price: $102.40 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 8 |
32128-45 |
NUT-HHF Price: $7.67 |
| 9 |
30-8770 |
WASHER Price: $3.43 |
| 10 |
69-7170-01 |
CLEVIS Price: $307.49 |
| 11 |
3233-29 |
SCREW-CARR Price: $8.69 |
| 12 |
3233-28 |
SCREW-CARR Price: $5.56 |
| 12 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 13 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587256501. Price: $49.99 |
| 14 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 15 |
71-2610 |
SHAFT-PIVOT, DECK Price: $251.69 |
| 16 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 17 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 18 |
98-1461-01 |
BAR-LIFT, LH Price: $504.26 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 19 |
98-7343 |
OUTSIDE ARM ASM Price: $792.23 |
| 20 |
13-5009 |
LH DECK ASM Price: $3,588.60 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
69-6730-01 |
SKID ASM Price: $264.77 |
| 22 |
3233-9 |
SCREW-CARR Price: $1.97 |
| 23 |
323-15 |
SCREW-HH Price: $1.53 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
5-0838 |
WASHER Price: $1.09 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
327-17 |
SCREW-HH Price: $8.50 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
106-6753 |
DECAL-DANGER, CE This part replaces 93-7815. Price: $8.07 |
| 27 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 27 |
532405357 |
SHIELD.DEFLECTOR.MOWER.46"BLAC Price: $49.99 |
| 28 |
93-4241 |
SPACER-BEARING, INNER Price: $26.72 |
| 29 |
120-5378 |
BEARING-BALL This part replaces 93-4237. Price: $13.84 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 32 |
98-7300-01 |
FORK-CASTOR ASM Price: $382.91 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
69-6860 |
WASHER-THRUST Price: $3.15 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
69-1510 |
SPACER Price: $4.48 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 36 |
95-0819 |
DECAL-BELT ROUTING, LEFT Price: $16.94 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 37 |
93-7824 |
DECAL-DANGER Price: $17.85 |
| 38 |
589676103 |
KEEPER 42 MANDREL BELT FOR 6.2 This part replaces 532432520. Price: $6.99 |
| 38 |
95-0818 |
DECAL-TORQUE Price: $22.79 |
| 39 |
106-8120 |
DECAL-DANGER, CE This part replaces 93-7273. Price: $9.83 |
| 39 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 40 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 42 |
93-4243 |
TIRE Price: $54.25 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 43 |
93-5980 |
HUB Price: $67.14 |
| 44 |
95-2741 |
RIM-WHEEL, HALF Price: $25.01 |
| 45 |
93-4244 |
TUBE-INNER (W/VALVE) Price: $14.42 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 46 |
93-4242 |
PLATE Price: $11.21 |
| 47 |
32128-16 |
NUT-HHF Price: $0.54 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 48 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
| 49 |
32144-11 |
SCREW-THD ROLL, HWH This part replaces 32104-31. Price: $6.99 |
| 50 |
94-9822-01 |
BAR-GUARD, WING INNER This part replaces 94-9822. Price: $76.20 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $14.99 |
| 64 |
532405139 |
LINKAGE.ASM.BRAKE.CLEAR.ZINC This part replaces 532405138. Price: $14.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
584453101 |
V-BELT.DRIVE.MWR.MECHANICL.46" This part replaces 532405143. Price: $49.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532199972 |
CLUTCH.ASM.MANUAL.YT.PREDATORQ Price: $49.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 144 |
531169801 |
SERVICE KIT BELT KEEPER This part replaces 532199204. Price: $4.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401872 |
SPRING RETURN Price: $4.99 |
| 152 |
584243501 |
CABLE.MECHANICAL.CLUTCH Price: $29.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 197 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 198 |
531170601 |
SERVICE KIT BAFFLE CENT This part replaces 532403149. Price: $9.99 |
| 200 |
596135501 |
Washers This part replaces 532413524. Price: $4.99 |
| 240 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
