| Ref | Part Number | Description |
|---|
| 1 |
13-2670-01 |
SHEAVE This part replaces 13-2670. Price: $1,182.76 |
| 2 |
120-5914-03 |
GUARD-SHEAVE Price: $581.15 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
93-4032 |
SHAFT-JACK Price: $245.00 |
| 4 |
56-6230 |
BEARING-ROLLER Price: $72.34 |
| 5 |
140-2208 |
PULLEY-DRIVE This part replaces 93-4033-01. Price: $163.75 |
| 7 |
114-8417 |
NUT-HF, NI Price: $0.87 |
| 8 |
117-8538-03 |
BRACKET-IDLER ARM Price: $44.63 |
| 9 |
117-8469-03 |
BRACKET-PULLEY Price: $20.10 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
3-8448 |
WASHER-THRUST Price: $2.58 |
| 11 |
100-7631 |
PULLEY-IDLER Price: $146.29 |
| 12 |
328-25 |
SCREW-HH Price: $4.07 |
| 12 |
532405472 |
RP_PULLEY ENGINE Price: $34.99 |
| 13 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 14 |
13-2680 |
BUSHING Price: $217.68 |
| 15 |
3232-3 |
BOLT-CARR Price: $2.14 |
| 15 |
529999102 |
TANK ASSY W/CAP 3 GAL CARB This part replaces 532414151. Price: $329.99 |
| 16 |
68-3220 |
KEY-STOCK Price: $4.60 |
| 17 |
13-3710 |
WASHER Price: $3.05 |
| 18 |
3247-6 |
SCREW-SET Price: $1.02 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 This part replaces 532430213. Price: $37.99 |
| 20 |
121-2780-03 |
GUARD-LOWER, BELT Price: $142.41 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
321-4 |
SCREW-HH Price: $0.99 |
| 24 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 26 |
93-4034 |
V-BELT Price: $204.67 |
| 27 |
322-7 |
SCREW-HH Price: $0.89 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 29 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 31 |
117-8506-03 |
MOUNT-GUARD Price: $49.01 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
