| Ref | Part Number | Description |
|---|
| 1 |
237-21 |
O-RING Price: $0.70 |
| 1 |
532411423 |
KIT.LEVER.CONTROL.RH.AUGER This part replaces 532184110. Price: $22.99 |
| 2 |
532184109 |
LEVER, TRACTION DRIVE CONTROL Price: $9.99 |
| 2 |
92-7637 |
HOSE ASM Price: $92.60 |
| 3 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 3 |
532179439 |
NUT, CAGE 1/4-20 Price: $2.99 |
| 4 |
21543921 |
ASSY, BLOCK 7 PISTON Price: $112.45 |
| 4 |
532178888 |
BUSHING, FLANGE Price: $3.99 |
| 4 |
98-2438 |
SUPPORT ARM WA - LH This part replaces 93-2717. Price: $1,174.09 |
| 5 |
21543870 |
SPACER Price: $9.95 |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 5 |
93-2699 |
PIN Price: $48.15 |
| 6 |
21543889 |
KIT, 10 CC BLOCK Price: $79.95 |
| 6 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 6 |
532199640 |
SCREW HEX This part replaces 532180402. Price: $3.99 |
| 7 |
2412-93 |
CLAMP-R Price: $1.02 |
| 7 |
532178652 |
ROD.INTERLOCK Price: $9.99 |
| 8 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 8 |
532184003 |
TUBE ASSM, INTERLOCK Price: $13.99 |
| 9 |
27105900 |
SCREW,HEX WASHER 1/4-20X1.125 Price: $1.95 |
| 9 |
532178651 |
TUBE.WELDMENT.INTERLOCK.LH Price: $20.99 |
| 9 |
92-7643 |
HYD HOSE ASM Price: $118.39 |
| 10 |
237-78 |
O-RING Price: $3.85 |
| 10 |
532178645 |
PANEL, CONTROL This part replaces 532184106. Price: $22.99 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 11 |
92-7632 |
HARNESS - WIRE Price: $758.90 |
| 12 |
67-1750 |
BUSHING Price: $0.92 |
| 12 |
874780528 |
SCREW Price: $4.99 |
| 13 |
33105-040 |
SCREW-HHF Price: $1.49 |
| 13 |
532436114 |
TUBE.HANDLE.LOOP.LH.BLACK This part replaces 532184107. Price: $54.99 |
| 14 |
53-6380 |
WASHER-FLAT Price: $8.62 |
| 14 |
532407857 |
TUBE.HANDLE.LOOP.RH.BLACK This part replaces 532184108. Price: $39.99 |
| 15 |
21543844 |
ROD, BYPASS Price: $7.54 |
| 15 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 16 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 17 |
94-1449 |
FITTING-STR,ORIF Price: $112.90 |
| 18 |
138-6956 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2631. Price: $692.61 |
| 18 |
532184594 |
ROD.AUGER.CONTROL Price: $54.99 |
| 19 |
21543783 |
TRUNNION, SWASHPLATE Price: $56.95 |
| 19 |
532193081 |
ROD.CABLE.TRACTION.LONG Price: $11.99 |
| 19 |
93-2700 |
ROLLER-PLASTIC Price: $30.55 |
| 20 |
33029-00 |
NUT-LOCK, NI Price: $2.92 |
| 20 |
532180428 |
ROD, END CONTROL Price: $8.99 |
| 21 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 21 |
596436301 |
Nuts This part replaces 873350500. Price: $2.99 |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 22 |
93-2705 |
LINK REAR *B Price: $9.45 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 23 |
93-2704-03 |
LINK-LEFT This part replaces 93-2704. Price: $23.18 |
| 24 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 25 |
94-8949 |
BUSHING-FLANGE Price: $2.51 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 26 |
93-2710 |
DISCONTINUED Price: Call Us |
| 27 |
08621500 |
SPRING. BLOCK Price: $1.45 |
| 27 |
871210616 |
Screw, Hex Head 3/8-16 x 1 Price: $4.99 |
| 27 |
93-6687 |
DECAL-NO STEP This part replaces 36-3400. Price: $14.45 |
| 27 |
94-4584 |
DECAL-DANGER, JAPAN Price: $38.17 |
| 28 |
08609400 |
WASHER. THRUST .59 X .79 X .04 Price: $1.45 |
| 28 |
532180494 |
PANEL CLIP Price: $2.64 |
| 28 |
93-4234 |
SCREW-HSH Price: $6.08 |
| 29 |
21543785 |
SHAFT, INPUT Price: $82.45 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
21543738 |
BRG, BALL 17X40X12 Price: $16.45 |
| 30 |
532182906 |
PANEL.CONSOLE.SNOW Price: $39.99 |
| 30 |
94-8948 |
BUSHING - STRAIGHT Price: $7.56 |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 31 |
94-8947 |
BUSHING-FLANGE Price: $4.54 |
| 32 |
21543773 |
WASHER 1.23X1.56X.04 Price: $5.45 |
| 32 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 32 |
93-7524 |
DISCONTINUED Price: Call Us |
| 33 |
532184111 |
ARM.LATCH.INTERLOCK.YELLOW Price: $3.99 |
| 33 |
93-9181 |
KNUCKLE - PIVOT *B Price: $573.32 |
| 34 |
532183518 |
BOLT, SHOULDER Price: $2.99 |
| 34 |
99-5610 |
PIN This part replaces 93-9161. Price: $40.16 |
| 35 |
08609100 |
BEARING. THRUST 30 X 52 X 13 Price: $14.95 |
| 35 |
873850400 |
This part replaces 532068038. Price: $2.51 |
| 35 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 36 |
21543708 |
WASHER .63X1.0X.05 Price: $3.45 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 36 |
82-8170 |
CLAMP Price: $17.27 |
| 37 |
532178658 |
SPRING, INTERLOCK Price: $2.99 |
| 37 |
93-7961 |
CLAMP-DRAIN, CASE Price: $12.42 |
| 38 |
21543807 |
GEAR, 13T PINNION Price: $4.45 |
| 38 |
532178666 |
HEADLIGHT.HALOGEN.SNOW Price: $219.99 |
| 38 |
93-7960 |
SPACER Price: $5.67 |
| 39 |
21543859 |
SHAFT, MOTOR Price: $70.75 |
| 39 |
532178668 |
BEZEL.HEADLIGHT.BLACK Price: $5.99 |
| 39 |
60-6700 |
BOLT-HH Price: $1.29 |
| 40 |
21543788 |
WASHER .71 X 1.16 X .04 Price: $2.95 |
| 40 |
92-8754 |
DISCONTINUED Price: Call Us |
| 41 |
21543724 |
WASHER .5X1.0X.032 Price: $2.95 |
| 41 |
92-8002 |
SWITCH-LIFT, BACK BIASED Price: $105.67 |
| 42 |
21543806 |
GEAR, 10T/48T Price: $25.55 |
| 42 |
98-8188 |
PIN WA W/NUT This part replaces 95-3461. Price: $9.33 |
| 43 |
21543781 |
GEAR, 10T JACKSHAFT Price: $11.35 |
| 43 |
93-2707 |
LINK WA Price: $175.04 |
| 44 |
21543793 |
JACK SHAFT (PIN) Price: $17.95 |
| 44 |
93-4248 |
DISCONTINUED Price: Call Us |
| 45 |
256-172 |
BUSHING Price: $4.57 |
| 46 |
33108-035 |
SCREW-HHF Price: $24.13 |
| 47 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 48 |
69-8980 |
WASHER Price: $0.58 |
| 49 |
94-1430 |
DISCONTINUED Price: Call Us |
| 50 |
340-78 |
NUT-LOCK Price: $1.63 |
| 51 |
94-1444 |
UNION-BULKHEAD Price: $33.59 |
| 52 |
21543935 |
KIT, SEALS AND RETAINING Price: $63.95 |
| 52 |
92-7635 |
DISCONTINUED Price: Call Us |
| 53 |
21543987 |
KIT, EXPANSION PLATE LH Price: $11.45 |
| 53 |
340-75 |
BULKHEAD-TEE Price: $45.10 |
| 57 |
21500059 |
KIT, CENTER SECTION, W/FILTER - LH Price: $136.95 |
| 58 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 59 |
21543937 |
KIT, BYPASS ARM Price: $9.45 |
| 61 |
21543958 |
KIT, FILTER Price: $15.45 |
| 100 |
21543851 |
DISC, COG BRAKE Price: $17.45 |
| 101 |
21500034 |
CAP, AXLE Price: $4.45 |
| 124 |
21544061 |
KIT, HUB 4 BOLT Price: $74.95 |
| 135 |
21543876 |
SPRING, EXTENSION Price: $4.45 |
| 138 |
21500057 |
Price: $13.95 |
| 139 |
21500058 |
Price: $11.95 |
| 140 |
21543867 |
ARM, NEUTRAL LEFT Price: $17.45 |
