| Ref | Part Number | Description |
|---|
| 1 |
4617J |
SUB= 532131861 Price: Call Us |
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
106983X |
HANDLE YT Price: Call Us |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 3 |
73710700 |
NUT LOCK YTH Price: Call Us |
| 4 |
74760612 |
SUB= 74780612 Price: Call Us |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
108451X |
ROD ASSEM YT Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 6 |
76020412 |
COTTER PIN Price: Call Us |
| 7 |
106308X |
SUB= 130171 Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
19292016 |
WASHER Price: Call Us |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 11 |
12000037 |
KLIP RING Price: Call Us |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
100734K |
SUB= 138057 Price: Call Us |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
110807X |
NUT T Price: Call Us |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
110729X |
ROD LIFT LT Price: Call Us |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
2876H |
SPRING T Price: Call Us |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
19131016 |
WASHER Price: Call Us |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
12000022 |
E-RING Price: Call Us |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
120174X |
SHAFT T Price: Call Us |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
121718X |
LEVER LIFT Price: Call Us |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
73680600 |
SUB= 73690600 Price: Call Us |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
122364X |
SUB= 125925X Price: Call Us |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
109413X |
GRIP Price: Call Us |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
74760412 |
BOLT LT Price: Call Us |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
110810X |
TRUNION LT Price: Call Us |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
19151216 |
WASHER Price: Call Us |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 27 |
9135R |
SPRING H Price: Call Us |
| 28 |
4939M |
SUB= 85902 Price: Call Us |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
19171516 |
WASHER T Price: Call Us |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
110448X |
PIVOT PIN T Price: Call Us |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
110029X |
LIFT LINK LT Price: Call Us |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 33 |
23180606 |
SCREW Price: Call Us |
| 35 |
121599X |
LH SUSP ARM ASM Price: Call Us |
| 37 |
121598X |
RH SUSP ARM ASM Price: Call Us |
| 38 |
73220800 |
NUT Price: Call Us |
| 39 |
8330H |
KEY STD Price: Call Us |
| 40 |
76020308 |
SUB= 3145 Price: Call Us |
| 41 |
73350600 |
NUT Price: Call Us |
| 42 |
19131312 |
WASHER Price: Call Us |
| 43 |
121252X |
UPSTOP Price: Call Us |
| 44 |
108236X |
BRACKET LT Price: Call Us |
| 45 |
17021008 |
SCREW Price: Call Us |
| 46 |
74760624 |
SUB= 74930624 Price: Call Us |
| 47 |
19121612 |
WASHER LT Price: Call Us |
| 48 |
108056X |
BUSHING YT Price: Call Us |
| 50 |
110447X |
SUB= 132793 Price: Call Us |
| 51 |
73360700 |
NUT Price: Call Us |
| 52 |
4921H |
SPRING.RETAINER Price: Call Us |
| 53 |
72140608 |
SUB= 72110608 Price: Call Us |
| 54 |
19131410 |
WASHER Price: Call Us |
| 55 |
110739X |
WASHER T Price: Call Us |
| 56 |
73980600 |
NUT SPECIAL T Price: Call Us |
| 58 |
73680400 |
SUB= 73690400 Price: Call Us |
| 59 |
19091616 |
WASHER Price: Call Us |
| 61 |
5320J |
SUB= 5320R Price: Call Us |
