| Ref | Part Number | Description |
|---|
| 1 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 3 |
70-7530 |
SPRING-COMPRESSION Price: $15.72 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 4 |
66-2720-03 |
VALVE LEVER ASM This part replaces 66-2720. Price: $56.12 |
| 5 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 6 |
63-7960 |
VALVE-LIFT Price: $636.36 |
| 7 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
237-65 |
O-RING Price: $2.50 |
| 10 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
237-22 |
O-RING Price: $2.43 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
66-3130 |
FITTING-SPECIAL Price: $76.51 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
66-8150 |
HOSE-HYDRAULIC Price: $15.32 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 15 |
66-8500 |
HYD HOSE ASM Price: $89.96 |
| 16 |
321-11 |
SCREW-HH Price: $0.36 |
| 17 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 18 |
76-4830-03 |
VALVE ROD ASM This part replaces 76-4830. Price: $38.97 |
| 19 |
283-16 |
PIN-CLEVIS Price: $2.37 |
| 20 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 21 |
3220-2 |
NUT-JAM Price: $0.50 |
| 22 |
282-27 |
CLEVIS-ADJ Price: $24.71 |
| 23 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 24 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 25 |
66-8190 |
HYDRAULIC HOSE ASM Price: $85.54 |
| 26 |
340-86 |
FITTING-TEE Price: $35.23 |
| 27 |
304-99 |
STEM-HOSE Price: $34.00 |
| 28 |
237-22 |
O-RING Price: $2.43 |
| 29 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
27-4240 |
PIN-CYLINDER Price: $21.90 |
| 31 |
63-6630 |
HYD CYLINDER ASM Price: $683.92 |
| 32 |
3216-3 |
SCREW-HH Price: $7.20 |
| 32 |
532180580 |
ROD TIE BALL J WSL Price: $109.99 |
| 33 |
66-8640 |
HYDRAULIC HOSE ASM Price: $104.12 |
| 34 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 35 |
340-70 |
NUT-LOCK Price: $2.10 |
| 36 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 37 |
63-7410 |
BRACKET-BULKHEAD Price: $9.20 |
| 38 |
321-4 |
SCREW-HH Price: $0.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
819182411 |
Washer 9/16 x 1-1/2 11 Ga. Price: $4.99 |
| 40 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 94 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
