| Ref | Part Number | Description |
|---|
| 2 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 4 |
67-8820-01 |
RH HINGE ASM This part replaces 67-8820. Price: $26.10 |
| 5 |
43-3900-03 |
FAN BELT GUARD ASM This part replaces 43-3900. Price: $290.98 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 9 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 10 |
67-8810-01 |
LH HINGE ASM This part replaces 67-8810. Price: $26.95 |
| 11 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 12 |
67-8190-01 |
BRACKET-SUPPORT, ENGINE This part replaces 67-8190. Price: $50.66 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 16 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 18 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 20 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 21 |
322-2 |
SCREW-HH Price: $0.69 |
| 22 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 23 |
237-30 |
O-RING Price: $2.50 |
| 24 |
43-8610 |
GUIDE Price: $23.35 |
| 25 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 26 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 27 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 28 |
237-7 |
O-RING Price: $8.82 |
| 29 |
218-461 |
NUT-HH Price: $2.50 |
| 30 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 31 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 32 |
86-7040 |
ROD-PROP, SEAT Price: $29.51 |
| 33 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 34 |
93-8472-01 |
GUARD - FLYWHEEL This part replaces 93-8472. Price: $77.00 |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468401 |
501468401 |
SPRING Price: $6.99 |
| 501468501 |
501468501 |
BALL Price: $6.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501666901 |
501666901 |
GASKET, PUMP SIDE Price: $14.99 |
| 501667701 |
501667701 |
SPRING Price: $7.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 501668301 |
501668301 |
LEVER Price: $14.99 |
| 502254701 |
502254701 |
PUMP DIAPHRAGM Price: $19.99 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503281620 |
536033701 |
CARBRETOR HD-12C H372 This part replaces 503281620. Price: $99.99 |
| 503281801 |
536033701 |
CARBRETOR HD-12C H372 This part replaces 503281801. Price: $99.99 |
| 503562401 |
503562401 |
SPRING Price: $6.99 |
| 503563401 |
503563401 |
INLET NEEDLE Price: $14.99 |
| 503574201 |
503574201 |
WELCH PLUG Price: $6.99 |
| 503647801 |
503647801 |
GASKET SET Price: $14.99 |
| 503688201 |
503688201 |
JET Price: $5.99 |
| 503799701 |
537077601 |
IMPULSE COVER This part replaces 503799701. Price: $4.99 |
| 503799801 |
503799801 |
COVER Price: $5.99 |
| 503799901 |
503799901 |
SHAFT Price: $11.99 |
| 503800001 |
503800001 |
THROTTLE FLAP Price: $4.99 |
| 503800401 |
503800401 |
NOZZLE Price: $3.99 |
| 503800701 |
503800701 |
GASKET Price: $64.99 |
| 503800801 |
503800801 |
SCREW Price: $19.99 |
| 503800901 |
503800901 |
SPRING Price: $8.99 |
| 503801101 |
503801101 |
SCREW Price: $4.99 |
| 503801401 |
503801401 |
TUBE Price: $3.99 |
| 503801501 |
503801501 |
BUSHING Price: $11.99 |
| 503855801 |
503855801 |
CHOKE FLAP Price: $3.99 |
| 503855901 |
503855901 |
RP NIPPLE Price: $17.99 |
| 503913901 |
503913901 |
LIMITER CAP Price: $2.99 |
| 503914001 |
503914001 |
LIMITER CAP Price: $4.99 |
| 503915401 |
503915401 |
CAP Price: $7.99 |
| 503943601 |
503943601 |
JET Price: $4.99 |
| 503943801 |
503943801 |
ADJUSTING SCREW Price: $5.99 |
| 503943901 |
503943901 |
IDLE SCREW Price: $7.99 |
| 503944001 |
503944001 |
JET Price: $9.99 |
| 504027213 |
504027213 |
IDLING SCREW Price: $5.99 |
| 504130905 |
504130905 |
GASKET Price: $2.99 |
| 505316717 |
505316717 |
SCREW Price: $6.99 |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
| 530035015 |
530035015 |
SCREW SHUTTERS Price: $2.99 |
| 537018901 |
537018901 |
LEVER Price: $3.99 |
| 537019001 |
537019001 |
SPRING Price: $8.99 |
| 537019101 |
537019101 |
CHOKE SHAFT Price: $14.99 |
