| Ref | Part Number | Description |
|---|
| 1 |
710-04043 |
SCREW 5/16-18 This part replaces GW-1186329. Price: $3.96 |
| 2 |
GW-1185403 |
RETAINER, 3/8 Not Available Price: |
| 3 |
GW-1757843 |
KNOB Not Available Price: |
| 4 |
736-3050 |
Washer, Plain (flat) 3/8, S.A.E. This part replaces GW-1107383. Price: $3.90 |
| 5 |
1737499 |
VACUCUT GRIP Not Available This part replaces GW-1737499. Price: |
| 6 |
GW-1185984 |
FLANGE NUT, 3/8-16 Not Available Price: |
| 7 |
GW-1177625 |
ROLL PIN .125 x . Not Available Price: |
| 9 |
1714782 |
Swivel Block This part replaces GW-1714782. Price: $22.11 |
| 10 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces GW-1186391. Price: $3.95 |
| 11 |
GW-1754424 |
CRANK SUPPORT Not Available Price: |
| 12 |
GW-1756141 |
CHUTE CONTROL SHAFT Not Available Price: |
| 13 |
GW-1735869 |
GEAR SUPPORT Not Available Price: |
| 14 |
GW-1100044 |
Hex Head Cap Screw, 5/16-18 x 3/4 Price: $3.76 |
| 15 |
GW-1724870 |
WORM GEAR Not Available Price: |
| 16 |
1724885 |
ROLL PIN Not Available This part replaces GW-1724885. Price: |
| 17 |
736-0262 |
FLAT WASHER .385X.870X.090 This part replaces GW-1100255. Price: $3.66 |
| 19 |
GW-1750691 |
WARNING DECAL Not Available Price: |
| 20 |
712-0291 |
Hex Lock Nut, 1/4-20 This part replaces GW-1734398. Price: $3.93 |
| 21 |
710-0389 |
Screw, Carriage, 3/8-16 x .75 This part replaces GW-1186126. Price: $3.89 |
| 22 |
GW-1757836 |
CHUTE CONTROL CRANK Not Available Price: |
| 23 |
GW-1745799001 |
FAN Not Available Price: |
| 24 |
714-0126 |
Key This part replaces GW-1200033. Price: $4.05 |
| 25 |
715-0143 |
Spring Spiral Pin, .25 x 1.25 This part replaces GW-1185348. Price: $4.04 |
| 26 |
GW-1185803 |
Grease Fitting Price: Call Us |
| 29 |
1185816 |
Special Washer This part replaces GW-1185816. Price: $3.15 |
| 30 |
710-0216 |
HEX SCREW 3/8-16 X .75 This part replaces GW-1100068. Price: $3.93 |
| 32 |
1186098 |
SCREW-CARR Not Available This part replaces GW-1186098. Price: |
| 34 |
1728567001 |
RUNNER (42010) Not Available This part replaces GW-1728567010. Price: |
| 35 |
712-0375 |
Hex Cent. L-Nut 3/8-16 Thd. This part replaces GW-1733398. Price: $4.02 |
| 36 |
GW-1111599 |
Hex Head Cap Screw, 1/4-20 x 5/8 Price: $3.63 |
| 37 |
GW-1100053 |
HEX HEAD CAP SCREW, 1/2-13 x 3/4 Not Available Price: |
| 38 |
736-0921 |
Lock Washer, 1/2 This part replaces GW-1100245. Price: $3.90 |
| 39 |
1100257 |
FLAT WASHER Not Available This part replaces GW-1100257. Price: |
| 40 |
GW-1185846 |
FLANGE BUSHING Not Available Price: |
| 41 |
GW-1720922 |
BEARING SUPPORT Not Available Price: |
| 42 |
GW-1185798 |
FLANGE BOLT, 3/8-16 x 1/2 Not Available Price: |
| 45 |
710-0260A |
Carriage Bolt, 5/16-18 x .62 This part replaces GW-1186097. Price: $3.71 |
| 46 |
GW-1741640 |
BEARING-BA Not Available Price: |
| 47 |
712-0161 |
Nut-Hex Ins L-#10- This part replaces GW-1772333. Price: $4.02 |
| 48 |
1103959 |
Flat Washer, #10 This part replaces GW-1103959. Price: $4.02 |
| 49 |
1724869099 |
HOLD-DOWN NYLON CLIP This part replaces GW-1724869. Price: $9.86 |
| 50 |
1752461 |
Sems Screw , #10-24 x 7/8 This part replaces GW-1752461. Price: $4.05 |
| 51 |
1757840010 |
SUPPORT-CHUTE Not Available This part replaces GW-1757840010. Price: |
| 52 |
GW-1757824 |
CHUTE ROD Not Available Price: |
| 53 |
GW-1750692 |
WARNING DECAL Not Available Price: |
| 54 |
GW-1723643001 |
ADJUSTING LEVER Not Available Price: |
| 56 |
714-0111 |
Cotter Pin This part replaces GW-1185147. Price: $4.20 |
| 57 |
GW-1737940 |
TRUSS-HEAD BOLT, #10-24 x 3/8 Not Available Price: |
| 58 |
GW-1732499 |
Lock Nut, 5/16-18 Price: $3.49 |
| 59 |
GW-1185838 |
FLANGE BEARING Not Available Price: |
| 60 |
GW-1737419 |
SET SCREW, 5/16-18 x 3/4 Not Available Price: |
| 61 |
GW-1752460 |
SHIM Not Available Price: |
| 62 |
GW-1714243 |
FLANGE BEARING Not Available Price: |
| 63 |
GW-1737957 |
NYLON WASHER Not Available Price: |
| 64 |
GW-1754572001 |
Housing Support Price: Call Us |
| 65 |
GW-1753357 |
SLEEVE Not Available Price: |
| 66 |
GW-1771718010 |
DISCHARGE CHUTE ASSEMBLY Not Available Price: |
| 68 |
GW-1750969 |
BUTTON PLUG Not Available Price: |
| 69 |
GW-1758058 |
SPUN SILVER INLAY Not Available Price: |
| 70 |
736-0140 |
Flat Washer, .385 x .62 x .063 This part replaces GW-1890945. Price: $6.20 |
| 71 |
GW-1917455 |
Housing Logo Decal Price: Call Us |
| 74 |
GW-1757860 |
HOUSING SIDE DECAL Not Available Price: |
| 76 |
GW-1771274 |
CHUTE DEFLECTOR Not Available Price: |
