General Assembly

General Assembly

Parts (78)

RefPart NumberDescription
1 787-01823A DECK Not Available Price:
2 731-07618 SHROUD Not Available Price:
3 731-07619 Mulch Door Not Available Price:
4 731-07620 DISCHARGE CHUTE Not Available Price:
5 731-07621 TRAILSHIELD Not Available Price:
6 734-04553 Front Wheel Price: $22.27
7 734-04554 REAR WHEEL Not Available Price:
8 731-07512 Wheel Cap Price: $3.65
9 721-04378 SHROUD SEAL Not Available Price:
10 731-07622 REAR DOOR Not Available Price:
11 731-07623 REAR BAFFLE Not Available Price:
12 731-07624 Mulch Plug Price: $18.47
13 711-05358 PIN Not Available Price:
14 732-04733 SPRING Not Available Price:
15 732-04734 SPRING Not Available Price:
16 787-01824A BRACKET (LH) Not Available Price:
17 787-01825A BRACKET (RH) Not Available Price:
18 711-05325 TRAILSHIELD ROD Not Available Price:
19 787-01813 MULCH DOOR BRACKET Not Available Price:
20 711-05326 Mulch Door Rod Price: $3.86
21 732-04713 MULCH DOOR SPRING Not Available Price:
22 611-04181 FRONT SHAFT ASSEMBLY Not Available Price:
23 741-04464 Spacer Bushing Price: $3.24
24 731-07511 WHEEL BUSHING Not Available Price:
25 611-04182 REAR SHAFT ASSEMBLY Not Available Price:
26 941-04465 SPACER BUSHING Not Available This part replaces 741-04465. Price:
27 732-04735 HEIGHT ADJUST PLATE Not Available Price:
28 732-04715 HEIGHT ADJUST SPRING Not Available Price:
29 720-04143 HEIGHT ADJUSTMENT KNOB Not Available Price:
30 787-01826 HEIGHT ADJUST ROD Not Available Price:
31 924-04088 MOTOR This part replaces 724-04088. Price: $196.62
32 736-04486 FLANGE Not Available Price:
33 731-07515 ELECTRIC MOTOR FAN Not Available Price:
35 731-07598 Washer Price: $3.49
36 736-04487 Washer Price: $3.86
37 712-04237 Nut Price: $3.49
38 731-07516 STRAIN RELIEF BRACKET Not Available Price:
39 731-07520 STRAIN RELIEF CAP Not Available Price:
40 725-05071 Resistor Price: $9.67
41 725-05119 Resistor Holder Price: $3.49
42 731-07599 RESISTOR BRACKET Not Available Price:
43 725-05118 RESISTOR BASE Not Available Price:
44 749-04670A UPPER HANDLE Not Available Price:
45 731-07522 HANDLE GRIP Not Available Price:
46 749-04688A LOWER HANDLE Not Available Price:
47 731-07523 Cord Retainer Price: $3.37
48 720-04145 QUICK RELEASE HANDLE Not Available Price:
49 736-04488 Washer Price: $3.58
50 720-04146 Quick Release Knob Price: $3.95
51 714-04086 QUICK RELEASE PIN Not Available Price:
52 715-04107 PIN Not Available Price:
53 712-04239 NUT Not Available Price:
54 712-04250 NYLOCK NUT Not Available Price:
55 720-04147 Wing Knob Price: $3.77
56 710-05082 Screw, M8 Price: $3.39
57 736-04489 Washer Price: $3.39
58 731-07524 CORD CLIP Not Available Price:
59 714-04088 SHOULDER BOLT Not Available Price:
60 731-07513 CAP Not Available Price:
61 625-04125 SWITCH BOX ASSEMBLY Not Available Price:
62 725-05115 AC Power Cord Not Available Price:
63 725-05116 MOTOR CORD Not Available Price:
64 747-05304 Grassbag Frame Not Available Price:
65 764-04096 Grassbag Price: $48.80
66 712-04251 LOCK NUT Not Available Price:
67 736-04497 FLAT WASHER Not Available Price:
68 710-05119 SCREW M4.2 x 16 Not Available Price:
69 710-05117 SCREW M6 x 12 Not Available Price:
70 712-04250 NYLOCK NUT Not Available Price:
71 710-05120 SCREW M4 x 12 Not Available Price:
72 712-04251 LOCK NUT Not Available Price:
73 716-04163 LOCK RING Not Available Price:
74 725-05121 RECTIFIER HEAT SINK Not Available Price:
75 725-05127 Rectifier Price: $11.59
76 710-05123 SCREW M4.8 x 16 Not Available Price:
77 710-05124 SCREW M4.2 x 25 Not Available Price:
78 710-05118 SCREW M5 x 12 Not Available Price:
79 710-05119 SCREW M4.2 x 16 Not Available Price:
