| Ref | Part Number | Description |
|---|
| 1 |
140064 |
SPRING CLUTCH MWR Price: Call Us |
| 1 |
99-5610 |
PIN Price: $40.16 |
| 2 |
122052X |
SPACER RETAINER Price: Call Us |
| 2 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880-01. Price: $350.23 |
| 3 |
73680600 |
SUB= 73690600 Price: Call Us |
| 3 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 4 |
130840 |
BRAKE ASM Price: Call Us |
| 4 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 5 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 5 |
131251 |
IDLER BELT GUIDE Price: Call Us |
| 6 |
121316X |
PULLEY IDLER Price: Call Us |
| 6 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 7 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 7 |
72110616 |
BOLT Price: Call Us |
| 8 |
19131410 |
WASHER Price: Call Us |
| 8 |
94-9998 |
WASHER-THRUST Price: $11.60 |
| 9 |
127744 |
SUB= 140092 Price: Call Us |
| 9 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 10 |
105-3359 |
NO. 4 LIFT ARM ASM Price: $923.86 |
| 10 |
72140610 |
BOLT.3/8-14X1.25 Price: Call Us |
| 11 |
130841 |
BRAKE ROD Price: Call Us |
| 11 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 12 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 13 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 13 |
72140506 |
BOLT Price: Call Us |
| 14 |
105-7948 |
HYD HOSE ASM Price: $226.47 |
| 14 |
73680500 |
SUB= 73690500 Price: Call Us |
| 15 |
105-7945 |
HYD HOSE ASM Price: $221.15 |
| 16 |
105-3347-03 |
FRAME-CARRIER, FRONT Price: $1,726.31 |
| 17 |
128508 |
MOWER LINK STAB Price: Call Us |
| 17 |
328-7 |
SCREW-HH Price: $4.00 |
| 18 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 19 |
105-7947 |
HYD HOSE ASM This part replaces 105-7946. Price: $217.43 |
| 20 |
105-0110 |
NO. 5 LIFT ARM ASM Price: $912.87 |
| 21 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 21 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 22 |
10030600 |
SUB= 10040600 Price: Call Us |
| 22 |
33114-020 |
SCREW-HH Price: $0.28 |
| 23 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 23 |
850857 |
BLADE BOLT Price: Call Us |
| 24 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 24 |
99-5621 |
GUIDE-HOSE Price: $34.45 |
| 25 |
83-6780 |
PIN-CYLINDER This part replaces 83-6780-01. Price: $130.51 |
| 26 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 27 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 28 |
153531 |
PULLEY.MAND.36/46 Price: Call Us |
| 28 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 29 |
137266 |
SUB= 139729 Price: Call Us |
| 29 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 30 |
136631 |
SUB= 532136631 Price: Call Us |
| 30 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 31 |
17490508 |
SCREW LT Price: Call Us |
| 31 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 32 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 33 |
131560 |
SUB= 532131560 Price: Call Us |
| 33 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 34 |
105-7947 |
HYD HOSE ASM Price: $217.43 |
| 35 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
| 36 |
110-9709 |
HYD CYLINDER ASM This part replaces 99-6986. Price: $743.86 |
| 36 |
121980X |
HINGE ROD Price: Call Us |
| 37 |
123713X |
SPRING TORSION Price: Call Us |
| 37 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 38 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 38 |
108-6715 |
GAUGE BAR ASM This part replaces 98-1852. Price: $148.12 |
| 39 |
19111016 |
WASHER Price: Call Us |
| 41 |
131264 |
V-BELT.PRIM.78.5. Price: Call Us |
| 42 |
19171616 |
WASHER Price: Call Us |
| 43 |
3146R |
RETAINER.SPRING Price: Call Us |
| 43 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 44 |
140608 |
KEEPER BELT LH Price: Call Us |
| 44 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 45 |
110485X |
BEARING Price: Call Us |
| 45 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 46 |
105-3351 |
BRACKET-SWITCH Price: $32.56 |
| 46 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 47 |
129895 |
BEARING.BALL Price: Call Us |
| 48 |
137645 |
SUB= 137646 Price: Call Us |
| 49 |
133943 |
HARDENED WASHER Price: Call Us |
| 62 |
153390 |
WASHER.FELT. Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
