| Ref | Part Number | Description |
|---|
| 1 |
614650 |
BOLT-SHOULDER Price: $3.28 |
| 2 |
105-1815 |
WHEEL GEAR ASM Price: $26.26 |
| 3 |
65-2720 |
RING-RETAINING,CLIP Price: $0.99 |
| 4 |
104-8670 |
GEAR-PINION, 13T Price: $18.59 |
| 5 |
105-6840 |
WASHER-THRUST Price: $1.29 |
| 8 |
137-9128 |
ARM-PIVOT, FRONT This part replaces 105-1807. Price: $5.46 |
| 9 |
105-1809 |
ARM-SPRING Price: $7.52 |
| 10 |
105-3042 |
KNOB-LEVER, HOC Price: $3.28 |
| 11 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 12 |
104-8698 |
RETAINER-BEARING, HOC Price: $7.65 |
| 13 |
104-8699 |
BEARING-BALL Price: $3.28 |
| 14 |
39-9650 |
SPRING-COMPRESSION Price: $2.01 |
| 15 |
612066 |
KEY Price: $1.74 |
| 16 |
106-3955 |
TRANSMISSION ASM Price: $73.32 |
| 17 |
105-6814 |
WASHER-PLAIN Price: $0.69 |
| 18 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 19 |
105-1833-03 |
BRACKET-PIVOT, FWD Price: $10.20 |
| 20 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 21 |
92-5791 |
SPACER Price: $9.99 |
| 22 |
91-2258 |
BELT-V Price: $17.50 |
| 23 |
104-8691 |
PULLEY-HALF, FRONT Price: $9.83 |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
3296-5 |
NUT-HEX Price: $3.09 |
| 26 |
105-1839 |
COVER-BELT, FRONT Price: $11.84 |
