| Ref | Part Number | Description |
|---|
| 1 |
532122614 |
Housing, Half L.H. Price: $175.99 |
| 1 |
58-9580-03 |
REST-FOOT Price: $291.45 |
| 2 |
532122615 |
Housing, Half R.H. Price: $133.99 |
| 2 |
60-0640-01 |
PEDAL-TRACTION Price: $172.47 |
| 3 |
532122616 |
Axle L.H. Price: $101.99 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
532122620 |
Axle R.H. Price: $91.40 |
| 4 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 5 |
532122621 |
Bearing, Ball Price: $45.99 |
| 5 |
60-2110 |
PIN Price: $1.42 |
| 6 |
48-6790 |
BEARING Price: $12.14 |
| 6 |
532122622 |
Washer, Flat 3/4 x 1-1/8 x .030 Price: $3.99 |
| 7 |
532122623 |
Gear, Miter Price: $15.99 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 8 |
532122624 |
Gear, Miter Price: $50.99 |
| 9 |
3-2858 |
DISC-FRICTION Price: $31.32 |
| 9 |
532122625 |
Nut, Hex Jam w/Patch 1/2-20 Price: $2.99 |
| 10 |
532122626 |
Shaft, Cross Price: $23.33 |
| 10 |
60-1130 |
LEVER Price: $177.91 |
| 11 |
3290-483 |
WASHER-CONICAL Price: $7.61 |
| 11 |
532122688 |
Screw, Stud Price: $4.99 |
| 12 |
325-9 |
SCREW-HH Price: $1.87 |
| 12 |
532122629 |
Snap, Ring Price: $2.99 |
| 13 |
47-7030 |
BUSHING-RUBBER Price: $31.76 |
| 13 |
532122631 |
Bearing, Thrust Price: $2.99 |
| 14 |
532122633 |
Housing Assembly, Differential Price: $130.99 |
| 15 |
33014-00 |
NUT-HEX Price: $0.25 |
| 15 |
532122634 |
Bearing, Flange Price: $8.99 |
| 16 |
3217-9 |
NUT-HH Price: $0.37 |
| 16 |
532122640 |
Gear, Differential 72 Tooth Price: $66.12 |
| 17 |
532122641 |
Bolt, Torx Head 1/4-28 x 5/8" Price: $2.99 |
| 18 |
33114-035 |
SCREW-HH This part replaces 48-7740. Price: $3.77 |
| 18 |
532155892 |
INPUT PINION This part replaces 532122642. Price: $234.99 |
| 19 |
48-7100 |
DAMPER-STEERING Price: $441.57 |
| 19 |
532122643 |
Snap, Ring Price: $2.42 |
| 20 |
3219-5 |
NUT-HEX Price: $1.22 |
| 20 |
532122644 |
Retaining Ring 7/16" Price: $2.99 |
| 21 |
532155892 |
INPUT PINION This part replaces 532122645. Price: $234.99 |
| 21 |
58-4310 |
COLLAR-PINNED Price: $51.49 |
| 22 |
532122646 |
Bearing, Needle Price: $21.79 |
| 22 |
58-5100 |
WASHER-TRACTION Price: $28.50 |
| 23 |
532122647 |
Bearing, Thrust Price: $11.99 |
| 23 |
60-5700 |
SPRING Price: $27.02 |
| 24 |
532122648 |
Washer, Flat 5/8 x 1-1/8 x .030 Price: $3.99 |
| 24 |
58-9010 |
TAB-CLAMP Price: $60.87 |
| 25 |
3274-89 |
SCREW-HSH Price: $8.07 |
| 25 |
532122649 |
Key, Hi-Pro 3/32 x 5/8 Price: $4.99 |
| 26 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 26 |
532122650 |
Screw, Hex W/Patch 1/4-20 x 3/4 Price: $3.03 |
| 27 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 27 |
532155892 |
INPUT PINION This part replaces 532122651. Price: $234.99 |
| 28 |
532170404 |
WASHER This part replaces 532123061. Price: $3.99 |
| 28 |
98-1209-03 |
LEVER-PUMP Price: $336.56 |
| 29 |
532122656 |
Pin, Cotter Price: $5.46 |
| 29 |
60-6990 |
WASHER Price: $4.62 |
| 30 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 30 |
532122653 |
Nut, Castle 5/16-24 Price: $2.38 |
| 31 |
3217-29 |
NUT-HEX Price: $0.25 |
| 31 |
532122660 |
Arm, Brake Actuator This part replaces 532122659. Price: $12.99 |
| 32 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 32 |
532122660 |
Arm, Brake Actuator Price: $12.99 |
| 33 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 33 |
532122662 |
Pin, Brake Actuating Price: $5.17 |
| 34 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 34 |
532122663 |
Brake, Yoke Price: $3.99 |
| 35 |
112-6500-01 |
BRACKET-LOCK, NEUTRAL This part replaces 60-0730-01. Price: $300.58 |
| 35 |
532122664 |
Disc, Brake Price: $10.40 |
| 36 |
532123065 |
Key, Hi-Pro 3/16 x 5/8" Price: $2.38 |
| 36 |
92-9228-03 |
LEVER Price: $170.54 |
| 37 |
3296-19 |
NUT-HEX Price: $0.65 |
| 37 |
532122666 |
Screw, Hex 1/4-20 x 1.50 Price: $3.08 |
| 38 |
532122667 |
Plate, Puck Price: $3.18 |
| 38 |
60-6740 |
WASHER Price: $2.31 |
| 39 |
532142883 |
SUB= 142883 This part replaces 532122668. Price: $4.99 |
| 39 |
92-9221 |
CABLE ASM Price: $19.69 |
| 40 |
532123066 |
Screw, Hex w/Patch 1/4-20 x 2.00 Price: $2.64 |
| 40 |
92-4730-03 |
PLATE-FLOOR Price: $1,213.65 |
| 41 |
532122670 |
Screw, Hex Self-Tap 1/4-20 x 2.00 Price: $3.99 |
| 42 |
532122671 |
Screw, Hex Self-Tap 1/4-20 x 3.00 Price: $2.38 |
| 42 |
60-0760 |
CLEVIS-ROD, TRACTION Price: $42.76 |
| 43 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 43 |
532122672 |
BALL BEARING This part replaces 532126982. Price: $29.99 |
| 44 |
33114-020 |
SCREW-HH Price: $0.28 |
| 44 |
532122673 |
Bearing, Ball Price: $28.99 |
| 45 |
532122674 |
Shaft, Pinion W/11 Tooth Gear Price: $116.99 |
| 45 |
58-0400-01 |
SHROUD Price: $472.86 |
| 46 |
532122675 |
Shaft, Drive Price: $193.99 |
| 46 |
62-7400 |
DECAL Price: $24.54 |
| 47 |
532123059 |
Bearing, Needle Price: $24.99 |
| 47 |
60-0600-03 |
BRACKET-PIVOT Price: $236.10 |
| 48 |
532123060 |
Bronze Thrust Brg. 5/8 x 1-1/4 x 7/64 Price: $7.99 |
| 48 |
60-1110 |
BUSHING Price: $15.95 |
| 49 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 49 |
532170404 |
WASHER This part replaces 532123061. Price: $3.99 |
| 50 |
325-7 |
SCREW-HH Price: $1.53 |
| 50 |
539122689 |
This part replaces 532122689. Price: $1.99 |
| 51 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 51 |
532121839 |
Coupling Price: $12.99 |
| 52 |
2411-44 |
END-ROD Price: $72.59 |
| 52 |
532126975 |
Gear, 60 and 17 Tooth Price: $118.35 |
| 53 |
532122682 |
Nut, Hex 1/4-20 Price: $2.38 |
| 54 |
532122683 |
Gear, Drive Pinion 17 Tooth Price: $17.22 |
| 54 |
76-3430 |
ROD-TRACTION Price: $79.20 |
| 55 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 55 |
532122684 |
Bolt, Square Head Price: $10.35 |
| 56 |
532122685 |
Washer 15/16 x .265 x .125 Price: $11.12 |
| 57 |
532122686 |
Washer, Spring Lock 1/4" Price: $2.38 |
| 58 |
532122687 |
Pin, Roll 3/16" x 1/2" Price: $2.99 |
| 59 |
532122652 |
Washer, Flat .62 x 1.0 x .030 Price: $11.99 |
| 60 |
532123062 |
Pin, Dowel 3/32 x 1/4 Price: $2.99 |
| 61 |
532123063 |
Seal, Grease Price: $2.74 |
| 62 |
532126977 |
Washer, Head Spring Lock 1/4" Price: $2.59 |
| 63 |
532126980 |
Assembly, Gear, Reduction Price: $90.99 |
| 64 |
532126981 |
Assembly, Shaft, Input Price: $47.01 |
| 65 |
322-6 |
SCREW-HH Price: $0.45 |
| 65 |
532126976 |
Shell Durina-O Grease (20 oz.) Price: $46.99 |
| 66 |
3218-2 |
NUT-JAM Price: $0.25 |
| 67 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 68 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 69 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 70 |
32128-20 |
NUT-HF Price: $0.99 |
| 71 |
33114-045 |
SCREW-HH Price: $0.68 |
| 72 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 73 |
3290-482 |
WASHER-BELLEVILLE Price: $5.87 |
