| Ref | Part Number | Description |
|---|
| 1 |
47-3650 |
CHAIN-LIFT, NO. 2 AND 3 Price: $119.48 |
| 1 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 2 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 3 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 3 |
532141342 |
KEEPER/MOWER DRIVE RH Price: $4.99 |
| 4 |
51-0850-01 |
SUPPORT-PULLEY This part replaces 51-0850. Price: $306.47 |
| 4 |
532138029 |
PULLEY.ENGINE.36/38 LR Price: $48.99 |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 5 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 6 |
47-3930-01 |
LOCKUP BRACKET ASM This part replaces 47-3930. Price: $270.92 |
| 6 |
871170744 |
Bolt, Hex Hd. 7/16-20 UNF Grade 5 Price: $2.99 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 7 |
532124525 |
BELT Price: $39.99 |
| 8 |
47-3640-01 |
CYLINDER REST ASM This part replaces 47-3640. Price: $44.42 |
| 8 |
532156109 |
BELT KEEPER KIT This part replaces 532123405. Price: $3.99 |
| 9 |
3290-216 |
WASHER Price: $3.83 |
| 9 |
872140612 |
Bolt, Carriage 3/8-16 UNC x 1-1/2 Price: $2.99 |
| 10 |
325-6 |
SCREW-HH Price: $1.42 |
| 10 |
532123396 |
KEEPER.BELT.GROUND.DRIVE.IDLER Price: $4.99 |
| 11 |
47-3870-01 |
RH CHANNEL ASM This part replaces 47-3870. Price: $235.39 |
| 11 |
532140911 |
ARM/GROUND DRIVE CLUTCH Price: $4.35 |
| 12 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 12 |
532123674 |
PULLEY.IDLER.FLAT Price: $24.99 |
| 13 |
26-8590 |
PIN-CYLINDER Price: $23.00 |
| 14 |
237-79 |
O-RING Price: $5.46 |
| 14 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 15 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 15 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 16 |
115-4949-01 |
HYDRAULIC CYLINDER ASM (14.00 STROKE) This part replaces 47-3720. Price: $1,376.05 |
| 16 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 17 |
20-4390 |
SPACER Price: $12.54 |
| 17 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 18 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 18 |
532131459 |
SPRING.EXTENSION Price: $4.99 |
| 19 |
42-3550-01 |
COVER-MOUNT, CYLINDER This part replaces 42-3550. Price: $108.41 |
| 19 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 20 |
3-0144 |
SHAFT Price: $53.89 |
| 20 |
532139919 |
KEEPER-T/A GROUND DRIVE BELT Price: $2.99 |
| 21 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 21 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 22 |
47-3860-01 |
LH CHANNEL ASM This part replaces 47-3860. Price: $215.68 |
| 22 |
532123404 |
KEEPER,FRA DR BEL Price: $3.22 |
| 23 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 23 |
532140916 |
KEEPER-MOWER DRIVE LH Price: $5.99 |
| 24 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 24 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 25 |
47-3010-01 |
TRAILER ASM This part replaces 47-3010. Price: $3,956.22 |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 28 |
60-9110-01 |
LIFT BAIL PIN ASM This part replaces 60-9110. Price: $84.41 |
| 29 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
47-3230-01 |
NO. 1 LIFT ARM ASM This part replaces 47-3230. Price: $907.15 |
| 32 |
32153-5 |
NUT-HEX Price: $1.59 |
| 33 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
47-3660 |
CHAIN-LIFT, NO. 1 Price: $197.71 |
| 36 |
5-2942 |
SHACKLE Price: $16.99 |
| 37 |
325-7 |
SCREW-HH Price: $1.53 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
