| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 1 |
75-9831 |
HYD MOTOR ASM Price: $1,646.04 |
| 2 |
3257-42 |
KEY-WOODRUFF Price: $5.99 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 4 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 5 |
83-9310 |
RH BRAKE LEVER ASM Price: $67.19 |
| 6 |
282-2 |
YOKE Price: $30.04 |
| 7 |
3220-2 |
NUT-JAM Price: $0.50 |
| 8 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
95-5824 |
ROD-ADJUSTMENT Price: $68.90 |
| 10 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
93-6850 |
LEVER-BRAKE Price: $59.75 |
| 12 |
70-9870 |
PLATE-BACKING Price: $183.14 |
| 13 |
321-4 |
SCREW-HH Price: $0.99 |
| 14 |
70-9880 |
SPRING-RETURN Price: $11.81 |
| 15 |
70-9840 |
SHOE-BRAKE Price: $60.36 |
| 16 |
10-6850 |
DRUM-BRAKE Price: $54.08 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
93-6838-03 |
HUB-WHEEL This part replaces 93-6838. Price: $72.59 |
| 18 |
85-8290 |
TIRE-2PLY, KNOBBY Price: $120.96 |
| 19 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 20 |
114-4643 |
WHEEL This part replaces 94-6116. Price: $149.61 |
| 21 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
85-6540 |
STUD-DRIVE Price: $7.41 |
| 24 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9860. Price: $42.42 |
| 24 |
532146148 |
CABLE BATTERY 6 GA 22" W/16W Price: $11.99 |
| 25 |
32120-47 |
RING-RETAINING, EXTERNAL Price: $0.99 |
| 25 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 26 |
325-13 |
SCREW-HH Price: $3.57 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000. Price: $8.08 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $12.99 |
| 29 |
92-1715 |
SPACER Price: $7.99 |
| 30 |
237-80 |
O-RING Price: $6.10 |
| 30 |
532175566 |
IGNITION SWITCH Price: $22.99 |
| 31 |
340-6 |
FITTING-STRAIGHT Price: $18.79 |
| 32 |
237-30 |
O-RING Price: $2.50 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 33 |
85-9390 |
DISCONTINUED Price: Call Us |
| 34 |
85-7760 |
DISCONTINUED Price: Call Us |
| 35 |
85-9400 |
DISCONTINUED Price: Call Us |
| 36 |
75-9840 |
HYD MOTOR ASM Price: $2,000.57 |
| 37 |
85-9410 |
TUBE-RH REAR MOTOR Price: $102.12 |
| 38 |
237-42 |
O-RING Price: $2.78 |
| 39 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 40 |
237-22 |
O-RING Price: $2.43 |
| 40 |
532188024 |
HARNESS.IGNITION Price: $119.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 41 |
85-0380 |
TUBE-MOTOR TO VALVE Price: $60.31 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $19.99 |
| 45 |
532122822 |
AMMETER Price: $17.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532169635. Price: $109.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 80 |
532146685 |
HARNESS, CLUTCH Price: $11.99 |
| 89 |
532169639 |
BRACKET SNAP-IN HOURMETER Price: $4.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
