Cylinder and Piston
Parts (39)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 137-6110 | TUBE ROLLER 3.0IN DIA X 24.5IN This part replaces 115-8297-03. Price: $273.64 |
| 1 | 507431705 | Screw Price: $0.99 |
| 2 | 114-5403 | SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 | 507431640 | Washer Price: $0.04 |
| 3 | 114-3717 | SEAL-OIL Price: $2.77 |
| 3 | 507476339 | Module & Switch Wire Ass'y. Price: $23.24 |
| 4 | 112-5290 | BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 | 507433248 | Switch Wire Price: $3.99 |
| 5 | 112-7494 | SEAL Price: $6.37 |
| 5 | 507430694 | Sleeve Price: $2.99 |
| 6 | 114-5411 | NUT-LOCK, BEARING Price: $24.46 |
| 6 | 503235111 | BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 7 | 302-5 | FITTING-GREASE Price: $0.59 |
| 7 | 507476096 | Spark Plug Boot & Clip Price: $1.96 |
| 8 | 507433473 | Cylinder Base Gasket Price: $1.99 |
| 9 | 507431655 | Nut Price: $0.99 |
| 10 | 507431675 | Screw Price: $0.99 |
| 11 | 507475623 | Grounding Switch Price: $5.28 |
| 12 | 507432302 | Washer Price: $1.99 |
| 13 | 530038387 | Switch Plate Price: $3.33 |
| 14 | 507475356 | Decompression Valve Price: Call Us |
| 15 | 507431706 | Washer Price: $2.99 |
| 16 | 507431691 | Screw Price: $1.99 |
| 17 | 507430684 | Muffler Gasket Price: $0.99 |
| 18 | 5074759848 | Muffler Body Price: Call Us |
| 19 | 507433096 | Muffler Channel Price: $3.99 |
| 20 | 507433104 | Muffler Screen Price: $8.99 |
| 21 | 5074764298 | Muffler Cover Ass'y. Price: Call Us |
| 22 | 5074761068 | Heat Shield Ass'y. Price: Call Us |
| 23 | 507431686 | Lockwasher Price: $1.99 |
| 24 | 530015718 | Screw Price: $0.24 |
| 25 | 507430993 | Screw Price: $0.48 |
| 26 | 507431683 | Lockwasher Price: $0.99 |
| 27 | 507430835 | Spacer Price: $1.99 |
| 29 | 507433475 | Wrist Pin Price: $9.99 |
| 30 | 507476558 | Piston & Rings Price: $30.28 |
| 31 | 507433476 | Retainer Price: $3.99 |
| 32 | 507476508 | Piston Ring Set Price: $24.99 |
| 50 | 114-5430 | ROLLER REBUILD KIT Price: $99.53 |
