| Ref | Part Number | Description |
|---|
| A |
530026156 |
Bow Guide Powerhead Price: $3.33 |
| A |
530026850 |
Guide Bar Powerhead Price: $0.12 |
| B |
530026921 |
Decal-Starting Instructions Price: $3.33 |
| C |
530025681 |
Guide Bar Powerhead Price: $2.99 |
| 1 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 1 |
530025948 |
Handguard Price: $7.99 |
| 2 |
3-7913 |
DISCONTINUED Price: Call Us |
| 2 |
530015406 |
Screw-10-24 x 1/2 Price: $1.99 |
| 3 |
36-8490 |
DISCONTINUED This part replaces 3-7921. Price: Call Us |
| 3 |
530001543 |
Nut - #10-24 Price: Call Us |
| 4 |
530024467 |
Cap - Handguard Price: $4.99 |
| 5 |
3-7878 |
THROTTLE CONTROL Price: $96.26 |
| 5 |
530015509 |
Screw - #10x1 - Pan Hd. - Handguard Price: $1.99 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
530024466 |
Handguard Price: $11.99 |
| 7 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 8 |
3217-7 |
NUT-HEX Price: $0.28 |
| 9 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 10 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 11 |
3-6718 |
DISCONTINUED Price: Call Us |
| 12 |
32146-4 |
NUT-LOCK, INSERT Price: $3.39 |
| 13 |
3-6685 |
SPRING Price: $10.99 |
| 14 |
3-7166 |
DISCONTINUED Price: Call Us |
| 15 |
3-6725 |
DISCONTINUED Price: Call Us |
| 16 |
32121-7 |
PIN-ROLL, SLOTTED Price: $0.31 |
| 17 |
322-20 |
SCREW-HH Price: $1.79 |
| 18 |
3290-220 |
Washer, Spring Price: Call Us |
| 19 |
32128-15 |
NUT-LOCK, FLANGE Price: $3.86 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 22 |
3220-2 |
NUT-JAM Price: $0.50 |
| 23 |
3-7168 |
DISCONTINUED Price: Call Us |
| 24 |
321-6 |
SCREW-HH Price: $0.25 |
| 25 |
3290-244 |
WASHER-LOCK Price: $0.85 |
| 26 |
3217-5 |
NUT-HEX Price: $0.25 |
| 27 |
5-1990 |
DISCONTINUED Price: Call Us |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
3220-1 |
NUT-JAM Price: $0.99 |
| 30 |
3296-19 |
NUT-HEX Price: $0.65 |
| 31 |
5-2576 |
Main Frame w/Ref. 32 Bshg. Price: Call Us |
| 32 |
5-1404 |
DISCONTINUED Price: Call Us |
| 33 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 34 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 35 |
323-7 |
SCREW-HH Price: $0.65 |
| 36 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 37 |
282-4 |
SHACKLE Price: $32.98 |
| 38 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 40 |
3-9316 |
Hook Eye Price: Call Us |
| 41 |
282-2 |
YOKE Price: $30.04 |
| 42 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 43 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 44 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 45 |
5-1420 |
Link Price: Call Us |
| 46 |
3-7157 |
SHOULDER BOLT Price: $47.07 |
| 47 |
5-2575 |
DISCONTINUED Price: Call Us |
| 48 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 49 |
256-188 |
BUSHING Price: $5.70 |
| 50 |
5-2582 |
ARM & BSHG ASM Price: $182.19 |
| 51 |
3219-2 |
NUT-HEX Price: $0.37 |
| 52 |
5-2620 |
DISCONTINUED Price: Call Us |
| 53 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 54 |
5-2580 |
DISCONTINUED Price: Call Us |
| 55 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 56 |
5-4015 |
SHOULDER BOLT This part replaces 5-3685. Price: $33.99 |
| 57 |
4-0639 |
DISCONTINUED Price: Call Us |
| 58 |
3220-7 |
NUT-JAM Price: $4.09 |
| 59 |
3-7875 |
Stabilizer, Spring Price: Call Us |
| 60 |
5-3661 |
BALL JOINT Price: $126.61 |
| 61 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 62 |
2411-20 |
Rod, Short Price: Call Us |
| 63 |
3-7855 |
Plate, Anchor Price: Call Us |
| 64 |
5-1421 |
Link Price: Call Us |
| 65 |
2411-23 |
Joint, Ball Price: Call Us |
| 66 |
3-7619 |
Frame w/(4) Ref. 55 Bshgs. Price: Call Us |
| 67 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 68 |
3-7854 |
DISCONTINUED Price: Call Us |
| 69 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 70 |
2411-21 |
Rod, Long Price: Call Us |
| 71 |
3-7873 |
Tube Support Price: Call Us |
| 72 |
3-7867 |
DISCONTINUED Price: Call Us |
| 73 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 74 |
3-7368 |
DISCONTINUED Price: Call Us |
| 75 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 76 |
3-6705 |
DISCONTINUED Price: Call Us |
| 77 |
323-25 |
SCREW-HH Price: $3.60 |
| 78 |
3-7872 |
Tube Support Price: Call Us |
| 79 |
3-6692 |
COMPRESSION SPRING Price: $16.89 |
| 80 |
3-6715 |
DISCONTINUED Price: Call Us |
| 81 |
3-6708 |
DISCONTINUED Price: Call Us |
| 82 |
5-1400 |
DISCONTINUED Price: Call Us |
| 83 |
39-5200 |
DISCONTINUED This part replaces 3-7145. Price: Call Us |
| 84 |
3-7246 |
DISCONTINUED Price: Call Us |
| 85 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 86 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 87 |
3256-28 |
WASHER-FLAT Price: $0.48 |
