| Ref | Part Number | Description |
|---|
| 1 |
108-1689 |
HOSE-HYD Price: $240.47 |
| 1 |
532434487 |
DECK.SVC.WELDMNT.30"419272X418 Price: $219.99 |
| 2 |
125-4574 |
TUBE ASM Price: $270.43 |
| 2 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 3 |
115-4372 |
TUBE-HYD Price: $128.79 |
| 3 |
596135701 |
GSPW Nuts Price: $2.99 |
| 4 |
115-4373 |
TUBE-HYD Price: $124.35 |
| 4 |
532417645 |
BRACKET.CLUTCH.CABLE Price: $4.99 |
| 5 |
121-3114 |
TUBE ASM Price: $149.40 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 6 |
125-4557 |
TUBE ASM Price: $117.22 |
| 6 |
532418863 |
ARMS.SUSP.MOWER.REAR.SRD Price: $17.99 |
| 7 |
115-4398 |
TUBE-HYD Price: $80.60 |
| 7 |
596321701 |
Screws Price: $2.99 |
| 8 |
115-4371 |
TUBE-HYD Price: $189.99 |
| 8 |
583379801 |
ARM.IDLER.30"SRD This part replaces 532420252. Price: $7.99 |
| 9 |
115-4370 |
TUBE-HYD Price: $205.88 |
| 9 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 10 |
125-1984 |
SPACER Price: $0.68 |
| 10 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 11 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 12 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 12 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $14.99 |
| 13 |
596136101 |
GSPW Bolts Price: $2.99 |
| 13 |
69-9010 |
WASHER Price: $1.83 |
| 14 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 15 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 16 |
120-8081 |
TUBE ASM Price: $179.63 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
125-4556 |
TUBE ASM Price: $218.61 |
| 17 |
596134801 |
Nuts Price: $1.00 |
| 18 |
120-8082 |
TUBE ASM Price: $98.35 |
| 19 |
105-3901 |
TUBE ASM Price: $182.03 |
| 21 |
121-3113 |
TUBE ASM Price: $170.16 |
| 21 |
532416910 |
KEEPER.BELT.MANDREL.30" Price: $12.99 |
| 22 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 23 |
125-4573 |
TUBE ASM Price: $268.54 |
| 23 |
599972501 |
BOLT This part replaces 596564003. Price: $2.99 |
| 24 |
596134901 |
GSPH Price: $2.99 |
| 25 |
529311701 |
KEEPER, BELT, BLACK This part replaces 532420253. Price: $4.99 |
| 25 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 26 |
340-128 |
NUT-BULKHEAD Price: $6.11 |
| 26 |
583481101 |
COVER.ASM.MANDREL.30" This part replaces 532420255. Price: $49.99 |
| 27 |
340-70 |
NUT-LOCK Price: $2.10 |
| 27 |
532419271 |
V-BELT.DRIVE.MOWER.30" Price: $49.99 |
| 28 |
94-5780 |
SCREW-HWH Price: $7.49 |
| 29 |
593885101 |
Rods Price: $5.99 |
| 30 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 32 |
532401872 |
SPRING RETURN Price: $4.99 |
| 32 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 33 |
340-72 |
FITTING-BULKHEAD, 90 DEG Price: $41.27 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL Price: $49.99 |
| 34 |
121-3112 |
TUBE ASM Price: $115.33 |
| 35 |
125-4555 |
TUBE ASM Price: $128.57 |
| 35 |
532419274 |
BLADE.MOWER.BAGGING.30" Price: $29.99 |
| 37 |
121-3115 |
TUBE ASM Price: $54.81 |
| 38 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 39 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 40 |
532419270 |
KEEPER.BELT.ENGINE.LH.LT.SRD Price: $14.99 |
| 41 |
532419265 |
KEEPER.BELT.ENGINE.RH.LT.SRD Price: $11.99 |
| 41 |
56-7977 |
CLAMP-TUBE Price: $1.76 |
| 42 |
69-9760 |
COVERPLATE Price: $5.38 |
| 42 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 43 |
322-10 |
SCREW-HH Price: $0.70 |
| 43 |
525568002 |
PULLEY.MANDREL 6.5" PULLEY This part replaces 532416877. Price: $24.99 |
| 44 |
125-4577 |
SPACER Price: $18.80 |
| 45 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 46 |
322-14 |
SCREW-HH Price: $1.01 |
| 47 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 48 |
69-9761 |
PLATE-COVER Price: $6.26 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 72 |
583364501 |
CHUTE.UPPER.SRD.30R" This part replaces 532417236. Price: $59.99 |
| 73 |
532425274 |
CHUTE.LOWER.SRD.30R" Price: $69.99 |
| 74 |
596919601 |
Pins Price: $2.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $29.99 |
