| Ref | Part Number | Description |
|---|
| 2 |
1916928 |
LABEL-FORW Not Available Price: |
| 3 |
710-0805A |
SCREW 5/16-18 x 1.5 LG This part replaces 1100799. Price: $3.75 |
| 4 |
710-0106 |
HEX SCREW 1/4-20 x 1.25 This part replaces 1100806. Price: $3.66 |
| 5 |
GW-55044 |
Bracket, Forward Clutch Cable This part replaces 55044. Price: $17.46 |
| 6 |
1916106001 |
FORWARD CLUTCH BAIL Not Available Price: |
| 7 |
710-04163 |
SCREW #10-24 x 2 Not Available This part replaces 9855. Price: |
| 8 |
732-04185 |
Spring, Forward Clutch This part replaces 1916712. Price: $6.21 |
| 9 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 10 |
712-3010 |
HEX NUT 5/16-18 This part replaces 1186230. Price: $3.89 |
| 11 |
9811 |
Hex Locknut, 1/4-20 Price: Call Us |
| 12 |
GW-55048P |
ASSM-CONTROL CABLE This part replaces 55048. Price: $30.52 |
| 13 |
710-0216 |
HEX SCREW 3/8-16 X .75 This part replaces 1100068. Price: $3.93 |
| 14 |
712-3000 |
Hex Lock Nut, 3/8-16 This part replaces 9837. Price: $3.90 |
| 15 |
736-3050 |
Washer, Plain (flat) 3/8, S.A.E. This part replaces 1107383. Price: $3.90 |
| 16 |
1100044 |
Hex Screw, 5/16-18 x 3/4 Price: $3.76 |
| 17 |
1916107001 |
SUPPORT-HANDLEBAR Not Available Price: |
| 18 |
912-0158 |
Hex Lock Nut, 5/16-18 This part replaces 1110107. Price: $2.83 |
| 19 |
753-06459A |
SERVICE REPLACEMENT KIT (GW-55043) This part replaces 1916108001. Price: $79.00 |
| 20 |
9386 |
Klip Ring Price: Call Us |
| 21 |
9856 |
Clevis Pin Price: Call Us |
| 22 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 9552. Price: $3.86 |
| 23 |
1901273010 |
PANEL-5510 Not Available Price: |
| 24 |
1917559 |
DECAL-LOGO 12193/1 Not Available Price: |
