| Ref | Part Number | Description |
|---|
| 6 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 9 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 15 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 16 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 17 |
532126197 |
WASHER Price: $6.99 |
| 19 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 20 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 21 |
532181454 |
NEEDS DESCRIPTION Price: Call Us |
| 22 |
532175896 |
ROD.BRAKE.HG-0510.PEDAL.CONTRL Price: $20.99 |
| 24 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 25 |
583201301 |
SPRING.ROD.BRAKE.GR This part replaces 532192036. Price: $3.99 |
| 26 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 27 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 28 |
532175765 |
ROD, PARKING BRAKE Price: $4.99 |
| 29 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 30 |
531149601 |
SERVICE KIT BRACKET BRKT This part replaces 532169592. Price: $8.99 |
| 32 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 33 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 34 |
532175578 |
SHAFT, FOOT PEDAL Price: $27.99 |
| 35 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 37 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532124963. Price: $3.99 |
| 38 |
532179114 |
PULLEY IDLER COMPOSITE Price: $19.99 |
| 39 |
872110622 |
BOLT Price: $3.99 |
| 41 |
532175556 |
KEEPER, BELT IDLER Price: $6.99 |
| 47 |
532139245 |
PULLEY IDLER This part replaces 532127783. Price: $32.99 |
| 48 |
532154407 |
BELLCRANK, CLUTCH Price: $5.99 |
| 49 |
531151801 |
SERVICE KIT RETAIN BELT RETAIN This part replaces 532123205. Price: $3.99 |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 51 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 This part replaces 532105710. Price: $8.99 |
| 55 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 56 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 57 |
532140294 |
DRIVE BELT, LTH & YTH TRACTORS Price: $34.99 |
| 59 |
532169691 |
KEEPER, BELT CENTER Price: $17.99 |
| 61 |
817490614 |
Screw, Hex Washer Hd. 3/8 - 16 x 7/8 This part replaces 817120614. Price: $3.20 |
| 62 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 63 |
532174607 |
PULLEY- ENGINE Price: $44.99 |
| 64 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 65 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 66 |
531151001 |
SERVICE KIT BELT KEEPER This part replaces 532154778. Price: $6.99 |
| 69 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 74 |
532137057 |
SPACER AXLE Price: $5.99 |
| 75 |
532121749 |
WASHER Price: $2.99 |
| 76 |
812000001 |
E-RING LT Price: $3.99 |
| 77 |
532123583 |
SQUARE KEY Price: $3.99 |
| 78 |
532121748 |
WASHER Price: $3.99 |
| 89 |
532191915 |
NEEDS DESCRIPTION Price: Call Us |
| 95 |
532180825 |
ROD BYPASS Price: $13.99 |
| 96 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 120 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 150 |
532175456 |
SPACER, RETAINER Price: $4.99 |
| 151 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 202 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 214 |
532174735 |
LINK TRANSAXLE Price: $37.99 |
| 217 |
532179433 |
PEDAL REVERSE Price: $19.99 |
| 218 |
532174713 |
ARM CONTROL PEDAL REVERSE Price: $5.99 |
| 219 |
532174839 |
BRACKET FREST PDL Price: $7.99 |
| 220 |
532174711 |
BRACKET MTG.PDL CONTROL Price: $11.99 |
| 221 |
872140606 |
Bolt - Rd. Hd. Sq. Neckiage 3/8 16 x 3/4 Price: $4.99 |
| 222 |
873680700 |
Nut, Crownlock Hex 7/16-14 unc Price: $2.99 |
| 223 |
532174840 |
WASHER NYLON Price: $4.99 |
| 224 |
532174736 |
PEDAL FORWARD Price: $69.99 |
| 225 |
532174712 |
ARM CONTROL PEDAL FORWARD Price: $16.99 |
| 226 |
532174902 |
BOLT PIVOT SPACER Price: $3.99 |
| 227 |
532174710 |
CAM REVERSE PEDAL LT Price: $5.99 |
| 228 |
532171873 |
BOLT, SHOULDER 5/16-18 This part replaces 532179032. Price: $4.99 |
| 229 |
532176451 |
WASHER.SERRATED.5/16X.75 Price: $3.99 |
| 231 |
532174573 |
STRAP TORQUE Price: $8.99 |
| 232 |
532175570 |
ACUATOR CRUISE DISENGAGE Price: $3.99 |
| 233 |
532174856 |
PAWL CONTROL CRUISE Price: $14.99 |
| 234 |
532174858 |
LEVER CONTROL CRUISE Price: $17.99 |
| 235 |
532174857 |
SECTOR CONTROL CRUISE Price: $3.99 |
| 236 |
532128903 |
BOLT Price: $5.99 |
| 237 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 238 |
532175807 |
ARM MTG.CRUISE SECTOR Price: $6.99 |
| 239 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 240 |
532175610 |
SPRING RETURN CRUISE CONTROL Price: $6.99 |
| 241 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873930400. Price: $3.99 |
| 242 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 243 |
532190736 |
BRACKET, ANTI-ROTATION Price: $24.99 |
| 244 |
594094101 |
Bolts This part replaces 817490510. Price: $1.99 |
| 251 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 253 |
532179422 |
WASHER Price: $4.99 |
| 254 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 263 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 272 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
| 273 |
532179610 |
NEEDS DESCRIPTION Price: Call Us |
| 274 |
532175646 |
COVER PEDAL FORWARD Price: $7.99 |
| 276 |
532178062 |
CLIP RETAINER Price: $2.99 |
