| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 1 |
86-1970 |
V-BELT Price: $94.70 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 2 |
84-1550 |
MOUNT-RUBBER Price: $27.49 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 3 |
86-2020 |
DISCONTINUED Price: Call Us |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 4 |
86-1990 |
WASHER-THRUST Price: $1.81 |
| 5 |
325-9 |
SCREW-HH Price: $1.87 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 6 |
93-6697 |
DECAL-LUBE This part replaces 70-2560. Price: $11.38 |
| 7 |
323-14 |
SCREW-HH Price: $1.34 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
100-2585 |
GEARBOX This part replaces 86-3090. Price: $3,295.02 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 10 |
86-1730 |
DISCONTINUED Price: Call Us |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 11 |
86-1830 |
COVER-DRIVESHAFT Price: $138.71 |
| 12 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 13 |
86-1910 |
WIRE HARNESS-DECK Price: $326.77 |
| 14 |
2412-138 |
R-CLAMP Price: $1.36 |
| 15 |
32128-23 |
NUT-HF Price: $1.51 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
86-1410 |
DISCONTINUED Price: Call Us |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 32 |
532180580 |
ROD TIE BALL J WSL Price: $109.99 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 94 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
